Playback Controls; Macro Editor - Strand Lighting NEO User Manual

User's Manual
Start/Stop Shortcut - Set a shortcut number to assign to the playback controls for this playback. Pressing the shortcut
will start the effect running. Pressing the shortcut while the effect is running will pause the effect and pressing it twice
within 2 seconds will rewind the effect to the start.
Loop Continuously - Check this option to make the effect loop back to the start when it finishes. If this option is not
checked then it will stop as soon as the effect ends.

Playback Controls

Along the bottom of the effect playback frame are the three playback controls and a progress time indicator.
Play
Use the play control to start the effect running. As soon as the effect starts the play control will be
highlighted in green and the time progress will beginning counting. In the case of simple chases the play
control is also used to step through the chase.
Pause
Pausing an effect will stop its execution immediately but keep the position pointer at the current location.
If you start the effect again, the effect will continue from this location.
At the bottom of the page is a button to pause all active effects. Pressing this is the equivalent of clicking
on the pause button of all running effects.
Rewind
Pressing the rewind button will stop the effect running and reset its position back to the start. If the effect
is started again, it will start from the beginning.
At the bottom of the page is a button to reset all active effects. Pressing this is the equivalent of clicking
on the reset button of all running effects.

23. Macro Editor

The macro editor is an enhancement to the Command Line interface and allows you to create a list of commands that
are executed in one operation.
NEO NOTES & TIPS: This is particularly useful if you have a sequence of commands that you use frequently.
Creating a macro enables you to activate the sequence in one operation rather than entering each command manually.
You can use the macro editor to create new macros or to edit existing ones.
Open the "Macro Editor" by clicking on the button at the bottom of the Command Line interface or by pressing F10
on your keyboard.
Figure 12: Macro Editor Screen
1 6 2
Software Configuration
