Chapter 18 System Setting and Maintaining
Once testing is completed, the trace files can be uploaded onto StrataSync for secure
storage and sharing. This sharing capability allows engineers who have a problem they
cannot resolve to request help from an expert who can analyze the trace file via StrataSync
using the JDViewer application from anywhere without having to be at the instrument, helping
resolve problems even faster.

Setting up Internet connection

Your JD720C series must have an access to the Internet to be able to connect to the
StrataSync. You can connect the Ethernet network to the RJ45 port of your instrument. You
can also use your mobile device's data network such as the Bluetooth tethering on an
Android-based smartphone and the Personal Hotspot on an iOS-based smartphone. If you
want to share your mobile's data network, you need to connect your instrument and your
mobile device.
Procedure
1
2
3
4
5
6
7
8
162
Connect one of the Parani-UD100 Bluetooth adapters to the USB port of your JD720C series.
Turn on Bluetooth on your mobile device, and then activate its tethering or hotspot.
–
On Android mobile devices:
a Go to Settings > Connections > Bluetooth.
b Check the box for Visible to all nearby Bluetooth devices to make your mobile device
discoverable by your JD720C series.
c Go to Settings > More networks > Tethering and portable hotspot.
d Check the box for Bluetooth tethering to enable sharing your mobile device's Internet
connection with your instrument.
–
On iOS mobile devices:
a Go to Settings > Bluetooth.
b Turn on Bluetooth.
c Go to Settings > Personal Hotspot.
d Turn on Personal Hotspot to make your mobile device discoverable by your JD720C
series and enable sharing your mobile device's Internet connection with your
instrument.
On your JD720C series instrument, press the MODE hard key, and then tap the System button.
The System window appears.
Touch the Bluetooth tab.
The Bluetooth setting window appears.
Tap the Start Scan button to discover your shared mobile device.
You will find your mobile device from the list in the Bluetooth Devices pane.
Highlight your mobile device name, and then tap the Select button.
A dialog box appears.
Tap the Connect button to pair and connect.
On your mobile device, enter 0000 in the PIN field, and then tap the OK button or Pair.
If the connection is successful, you mobile device is displayed under the Connected Device in the
Connection Information pane.
CellAdvisor JD720C User's Manual
