Preparing for fiber inspection

Connecting a fiber microscope

Connecting an optional fiber microscope P5000i is mandatory for fiber inspection and
analysis. See "Fiber microscope kits" on page 170 for available options.
Procedure
1

Selecting measurement mode

Procedure
1
2
3

Setting parameters

You can set testing parameters such as analysis profile, tip, test button, and auto center. You
can also select the profile and the tip from the drop-down lists activated on the Live screen.
Procedure
1
2
Connect your fiber microscope P5000i to one of the USB Host ports of the JD720C series.
The instrument detects the connected video microscope automatically.
The Fiber Inspection icon and name appears on the measurement mode screen.
Press the MODE hard key and then select the Single Layout tab.
Double-tap the Fiber Inspection icon.
Optional. To check the connected fiber microscope such as model number, version, and serial
number, complete the following steps:
a Press the SETUP hard key and then touch the Info/Setting tab.
The information and setting window appears.
b Tap the Cancel button to exit.
Press the SETUP hard key and touch the Info/Setting tab.
The information and setting window appears.
To select one of the pre-configured analysis profiles that match the PASS/FAIL criteria in the IEC
visual inspection standard, complete the following steps:
a Tap the drop-down list button for the Profile.
b Select the profile that you want to use, from the following choices:
–
MM (IEC-61300-3-35)
–
Ribbon, MM (IEC-61300-3-35)
–
Ribbon, SM APC (IEC-61300-3-35)
–
SM APC (IEC-61300-3-35)
–
SM PC (IEC-61300-3-35)
–
SM UPC (IEC-61300-3-35)
NOTE
All of the profiles are factory set and cannot be edited or removed.
