- Page 1 BOEING 787: FIBEr INspEctION aNd clEaNING Inspect with FBP Probe and HD-series Display; Clean with CleanBlast System UsEr MaNUal Zp-pKG-0554 rEV 0...
- Page 2 Notice Every effort was made to ensure that the information in this document was accurate at the time of printing. However, information is subject to change without notice, and JDSU reserves the right to provide an addendum to this document with information not available at the time that this document was created.
-
Page 3: Table Of Contents
cONtENts Introduction to Fiber Inspection Fiber Inspection Overview ............... Inspect Before You Connect ..............Benefits of Proactive Inspection ............Fiber Optic Connectors Single Fiber Connectors ................Mil-Aero Connectors ARINC 801 ......................Key Terms ......................JDSU Alignment Guides ................Effect on Signal Performance The Problem ....................... -
Page 4: Introduction To Fiber Inspection
INtrOdUctION tO FIBEr INspEctION FIBER INSPECTION OVERVIEW Contamination is the number 1 reason for troubleshooting optical networks. A single particle mated into the core of a fiber can cause significant back reflection, insertion loss, and equipment damage. Visual inspection is the only way to determine if fiber connectors are truly clean before mating them. -
Page 5: Fiber Optic Connectors
FIBEr OptIc cONNEctOrs SINGLE FIBER CONNECTORS Also called simplex connectors, these types contain a single fiber located in the center of a ceramic zirconia ferrule. The alignment of the mated connectors/fibers is achieved inside a ceramic or bronze mating sleeve within the bulkhead adapter. -
Page 6: Mil-Aero Connectors
MIl-aErO cONNEctOrs Receptacle ARINC 801 Mil-Aero connectors are fiber optic connectors used in aerospace applications. Established by the Airlines Electronic Engineering Committee (AEEC), ARINC 801 is part of the ARINC 800 series of fiber optic standards for avionics networking. All ARINC 801 connectors utilize a 1.25 mm ferrule and are mated in a pin and socket configuration. -
Page 7: Effect On Signal Performance
EFFEct ON sIGNal pErFOrMaNcE THE PROBLEM Dirt is everywhere, and a typical dust particle (2–15 μm in diameter) can significantly affect signal performance and cause permanent damage to the fiber end face. Most field test failures can be attributed to dirty connectors, and most of them are not inspected until the problem is detected, after permanent damage has already occurred. -
Page 8: Inspect Before You Connect
INspEct BEFORE YOU cONNEct THE SOLUTION INSPECT Before YoU CoNNECT By implementing a simple yet important process of proactively inspecting and cleaning before mating, you can prevent poor signal performance and equipment damage. PROACTIVE INSPECTION Loose debris and dirt are much easier to clean prior to mating the 2 connector sides. By visually inspecting fiber connectors at every stage of handling before mating them, you are proactive in preventing signal loss and equipment damage. -
Page 9: Where Inspection Should Occur
WhErE INspEctION shOUld OccUr Inspection of fiber end faces is CRITICAL at EVERY STAGE of handling fiber. Connector Manufacturing Aircraft Assembly Maintenance harness Test Flight Line BOEING 787: FIBEr INspEctION aNd clEaNING... -
Page 10: Inspect
INspEct: BulkHeaD (Single Fiber Connectors) INSPECT INSTALL TIP AND BARREL ASSEMBLY Install the appropriate inspection tip and barrel assembly (FBPP-BAP1) to the probe microscope. Note: Standard tips require barrel assembly. Inspection Tip Barrel Assembly INSPECT BULKHEAD Insert the probe into the bulkhead to inspect. - Page 11 INspEct: PatCH CorD (Single Fiber Connectors) INSPECT INSTALL TIP AND BARREL ASSEMBLY Install the appropriate inspection tip and barrel assembly (FBPP-BAP1) to the probe microscope. Note: Standard tips require barrel assembly. Inspection Tip Barrel Assembly INSPECT PATCH CORD Attach the patch cord to the probe microscope to inspect.
- Page 12 INspEct: arINC reCePtaCle (Mil-aero) INSPECT INSTALL BARREL ASSEMBLY / TIP Install the barrel assembly (FBPP-BAP3 or FBPP-BAP3-A6) to the probe microscope. Note: No additional inspection tip is necessary when using guides. Barrel Assembly (FBPP-BAP3 shown) Align the ARINC alignment guide for receptacle (FBPT-A801-2002R) and insert into either side of the receptacle (pins or socket).
- Page 13 INspEct: arINC Plug (Mil-aero) INSPECT INSTALL BARREL ASSEMBLY / TIP Install the barrel assembly (FBPP-BAP3 or FBPP-BAP3-A6) to the probe microscope. Note: No additional inspection tip is necessary when using guides. Barrel Assembly (FBPP-BAP3 shown) Align the ARINC alignment guide for plug (FBPT-A801-2001P) and insert into either side of the receptacle (pins or socket).
-
Page 14: Clean
clEaN: CoMMoN MetHoDS CLEAN Note: For Cleanliness Acceptance Criteria, see the Aircraft Maintenance Manual (AMM) for the Boeing 787. CLEAN BULKHEAD SwAB Use the swab to clean the bulkhead by inserting into bulkhead, applying slight pressure, and twisting the swab 2 to 3 times. Inspect again, and repeat if necessary. - Page 15 clEaN: JDSu CleaNBlaSt™ SySteM CLEAN CLEANING WITH CLEANBLAST To clean receptacles with the CleanBlast system: Run Button Install the appropriate cleaning tip to the Cleaning Tip CleanBlast handset. PRIME the nozzle if necessary (see CleanBlast User Manual). Align the alignment guide and insert into either side of the receptacle or plug (pins or socket).
-
Page 16: Connect
cONNEct CONNECT GOOD FIBER CONNECTION There are 3 basic principles that are critical to achieving an efficient fiber optic connection: Perfect Core Alignment Physical Contact Pristine Connector Interface Light Transmitted Clean Connection Cladding Core Today’s connector design and production techniques have eliminated most of the challenges to achieving core alignment and physical contact. -
Page 17: Fbp Probe Microscope
FBp prOBE MIcrOscOpE FBP PROBE OVERVIEW JDSU FBP-series probes are portable video microscopes used to inspect fiber optic connectivity. While most fiber microscopes are limited to inspecting male connectors, JDSU's FBP probe is designed to inspect both simplex and multi-fiber (ribbon) types of both male and female connectors, as well as optical devices such as transceivers. The probe is specially designed to fit and operate comfortably and easily in-hand, allowing the user to inspect hard- to-reach connectors that are installed on the backside of patch panels or inside hardware devices. - Page 18 JdsU INspEctION tIps, GUIdEs, BarrEl assEMBlIEs INSPECTION TIPS AND GUIDES To optimize the performance and safety of fiber inspection, the probe microscope is used in conjunction with various interchangeable tips and guides. Each tip or guide is specifically designed to accessibility and accurate inspection for every connector on the aircraft without causing harm to the connections.
-
Page 19: Tips, Guides, And Barrel Assemblies Map
tIps, GUIdEs, aNd BarrEl assEMBlIEs Map TIPS/GUIDE INSTALLATION GUIDE FBPT Inspection Tips Barrel Assembly Standard Patch Cord Tips FBPP-BAP1 Standard Bulkhead Tips Alignment Guides FBP Probe Microscope FBPP-BAP3 Description Attach this barrel assembly directly FBpp-Bap1 onto the P5 probe and use with the various inspection tips for inspecting fiber connectors. -
Page 20: Hd1 Video Display
hd1 VIdEO dIsplaY HD1 DISPLAY OVERVIEW The JDSU HD1 Video Display is a durable, 3.5-inch TFT lightweight, ergonomic, drop-tested display for use LCD Screen with any NTSC FBP or FBP3 series probe. It features a 3.5-inch TFT active matrix LCD screen, which produces a bright, clear and crisp, high-contrast image of the oN/oFF Control... -
Page 21: Fbp3 Long Reach Probe And Tips
FBp3 lONG rEach prOBE aNd tIps FBP3 PROBE OVERVIEW As system capacities have increased, optical connectors have proliferated in backplane applications. Increasingly, those connectors are ribbon ferrule based. The FBP3 series is purpose-built for reaching between adjacent cards/ modules to reach optical connectors in the backplane. The FBP3-P3L is a long-reach backplane probe that is designed to inspect connectors that are otherwise difficult to access. -
Page 22: Jdsu Cleanblast System
JdsU clEaNBlast sYstEM CLEANBLAST SYSTEM OVERVIEW The patented JDSU CleanBlast fiber end face cleaning systems provide a fast, effective, and cost-efficient solution for removing dirt and debris from connectors in most common applications. CleanBlast is a non- contact system that uses a highly filtered stream of pressurized gas with a vacuum circuit to create a high flow rate jet across the surface of the fiber. - Page 23 BOEING 787 cONFIGUratIONs FBP-787-1 Boeing 787 - Basic Avionics Inspection Kit Part Number Description FBP-HD1 HD1 - Handheld Video Display, 3.5-inch LCD FBP-P5-H P5 Probe - Video Inspection Probe, 200/400X, EMI Hardened, 4-pin Out FBPT-C130 Interface Tip, for Standard Video Probe (P5), for Use with Locking Guides FBPP-BAP3 Barrel Assembly, for P5 Probe, Narrow Type, for Use with Guides FBPP-BAP3-A6...
- Page 24 FAX: 1 301 353 9216 FAX: +1 954 345 4668 FAX: +852 2892 0770 FAX: +49 7181 86 1222 Product specifications and descriptions in this document subject to change without notice. © 2010 JDS Uniphase Corporation. August 2010 Zp-pKG-0554 reV 0...
