5.7 Robot connection

The cable from the robot must be plugged into the connector at the bottom of the
control box, see illustration below. Ensure that the connector is properly locked before
turning on the robot arm. Disconnecting the robot cable may only be done when the
robot power is turned off.
UR3/CB3
Parameter
Input voltage
External mains fuse (@ 100-200V)
External mains fuse (@ 200-240V)
Input frequency
Stand-by power
Nominal operating power
DANGER:
1. Make sure that the robot is grounded correctly (Electrical con-
nection to earth). Use the unused bolts associated with ground-
ing symbols inside the controller box to create common ground-
ing of all equipment in the system. The grounding conductor
shall have at least the current rating of the highest current in the
system.
2. Make sure that the input power to the controller box is protected
with a RCD (Residual Current Device) and a correct fuse.
3. Lockout and tagout all power for the complete robot installation
during service. Other equipment shall not supply voltage to the
robot I/O when the system is locked out.
4. Make sure that all cables are connected correctly before the con-
troller box is powered. Always use an original and correct
power cord.
I-46
5.7 Robot connection
Min Typ Max Unit
100 - 240 VAC
8 - 16 A
8 - 16 A
47 - 63 Hz
- - 0.5 W
90 150 325 W
