Instrument

Introduction
This section provides an overview of ÄKTA start.
Illustration of the instrument
modules
The illustration below shows the locations and gives brief descriptions of the modules
placed on the wet side of the instrument.
1
2
3
Part
1
ÄKTA start Maintenance Manual 29-0603-08 AC
8
4
Function
Buffer valve
9 10
5
Description
A 3-port valve that is used as a switching valve
for gradient formation. It enables the use of two
buffers, which are required for forming a gradient
during runs.
3 System description
3.2 Instrument
