Step
4
5
6
ÄKTA start Maintenance Manual 29-0603-08 AC
Action
Set the Light strength value to 500 using up/down arrows or enter the value.
Tap Calibrate.
Result: A confirmation screen opens.
Tap OK to automatically adjust the Light strength value to get a minimum
Signal response of 2500 mV.
If the Signal value is above 2500 mV, tap Save.
•
If the Signal value is below 2500 mV use the arrows to increase the Light
•
strength until the Signal is above 2500 mV.
Tap Save.
Result: The calibrated Light strength value is saved and stored in the perma-
nent memory on main board.
5 Service and settings
5.4 UV Monitor
5.4.1 UV LED calibration
