GE Medical Systems
Information Technologies

2 General Overview of the Dash Responder

GE Medical Systems Instrument Part Numbers

Configuration of Instrument Part Numbers

The instrument part number comprises of ten digits, the first seven digits determine the instrument type
and the last three—separated by a hyphen—the instrument version.
The user language is determined by configuration, thus is no part of the instrument number.

Configuration of the PCB Part Numbers

The number of the PCB is listed on the barcode label. The label can be seen on the PCB without
dismounting.
As some PCBs need additional tests before they get delivered as field replacement boards, this boards
and assemblies were given separate spare part numbers.
Therefore were special field replacement spare parts are available this need to be ordered (see Spare
Parts List on page 64).
The affiliated documentation, e.g. reference diagrams, circuit diagrams and parts lists are listed under
the part number of the PCB part number.

Instrument status documentation

Due to hardware and software combination, unambiguous documentation of the instrument assembly
status is necessary also in event of repairs.
Master Record Index
2002550-013
The master record index lists the valid configurations for the Dash Responder. Numbers for all
permissible components of the device are listed. Spare part numbers are provided where available.

Instrument Versions of the Dash Responder

CAT No
2002550-001
2002550-002
Revision F
2004768-001
Description
DASH RESPONDER, MANUAL
DASH RESPONDER, MANUAL, PACER
Servicing Manual Dash Responder V1.0
Page 9 of 72
