Illustration of the modules
The illustration below shows the locations of the modules placed on the wet side of the
instrument.
1
2
3
Part
1
2
3
4
5
6
7
8
ÄKTA start Maintenance Manual 29-0603-08 AC
8
4
Module
Buffer valve
Mixer
Sample valve
Pump
Pressure sensor
Wash valve
Injection valve
UV
9 10
5
Disassembly instructions
Instructions, on page 149
Instructions, on page 153
Instructions, on page 163
Instructions, on page 167
-
Instructions, on page 175
Instructions, on page 186
Instructions, on page 156
7 Disassembly
7
6
