Step 2. Remove the Cassette
Open the imagesetter top cover and the light shield.
Figure 4.11. Left, top cover and light shield open.
540.MediaCoverUp.art
Center and right, sliding the supply cassette out of the imagesetter
Pull the cassette gently but firmly out of the imagesetter.
Use the handles built into the cassette. Keep the cassette
straight as you pull it out.
If you are removing a cassette that still contains media,
about one inch (2.5 cm) of media will protrude past the open-
ing of the cassette. You can rewind this back into the cas-
sette or trim it off.
To rewind the media, turn the gear that appears at one end
of the supply cassette.
Caution:
Do not rewind the media all the way into the cas-
sette. If you rewind the media too far, you need to
open the cassette in a darkroom to pull the end
out. Opening the cassette in normal room light will
expose a large quantity of the media in the cas-
sette.
