Offline Operation

You can bypass the bridge and feed media directly into the processor
from a take-up cassette.
Built into the front of the processor is a lid. Below the lid is an input
tray with various foam light seal adapters, for use with different size
take-up cassettes.
Follow this procedure.
Step 1: Raise the input lid.
Step 2: Select the appropriate adapter for the take-up cassette you
are using.
Step 3: Pull approximately 6 to 8 inches (15.2 to 20.3 cm) of media
from the cassette as a leader.
Step 4: Start the leader in the input slot while observing the indica-
tors of the OLP. Ensure that the indicators activate (Film
Input Left, Film Input Right).
Step 5: Lower the cassette fully into the foam adapter.
Note: The input lid of the processor must remain open
while using this feature. This generates error 59, Pro-
cessor Top Door Open on the imagesetter control panel.
This message automatically clears as soon as you close
the lid.
Step 6: If you get an "Input Jam" message at the processor after
placing the cassette onto the adapter and observing the Film
Input indicators, the leader was not long enough. The media
reached the Input Sensors but not the rollers. Remove the
cassette and pull an additional 2 inches (5.1 cm) of media
from the cassette. Clear the error by pressing the processor
On/Off key and re-insert the media.
