Parts of the Imagesetter

The SelectSet Avantra imagesetter is designed for ease of use. This sec-
tion describes the basic components.

Media Compartment

The media compartment contains the supply cassette, the take-up cas-
sette, and cutter.
• Supply Cassette
Holds unexposed media. You load it with bulk rolls of media.
• Take-up Cassette
Holds exposed media. A take-up cassette is supplied with the im-
agesetter.
• Cutter
Cuts media when you are ready to remove the take-up cassette to
process exposed media. The cutter can be activated from either the
control panel or the front end of your imaging system.
On systems equipped with the optional Avantra 20/25 OLP, the media
transport bridge is installed in the media compartment.

Main Power Switch

The main power switch is located at the front of the imagesetter, to the
left of the control panel. See Figure 1.1.
