Start Up and Shut Down Procedures

Follow these steps to start the SelectSet Avantra.
Step 1: Turn on the imagesetter. Press the green side of the switch
located next to the control panel. A progress bar appears at
the bottom of the screen as the imagesetter boots up.
SelectSet Avantra
Diagnostics
Startup V.1.01
Figure 2.1. Screens that appear as you start up the SelectSet Avantra.
Step 2: When the control panel displays message 15 (No RIP), turn
on the RIP. Follow the instructions in the manuals that come
with your RIP.
Step 3: When both the imagesetter and the RIP are ready, the con-
trol panel shows a display called the Run Screen.
If there is no media loaded, or if there is no take-up cassette
in place, or if the bridge for the on-line processor is out of po-
sition, the Pause Screen appears instead of the Run Screen.
Figure 2.2. In some cases, the Pause Screen appears
2–2 • SelectSet Avantra User Guide
SelectSet Avantra
Diagnostics
Startup V.1.01
when you start up the imagesetter.
15
