AGFA SelectSet Avantra User Manual page 146

Imagesetter.
Bridge.
Processor.
Nip rollers and cutter.
Bridge entry sensor.
Bridge center sensor.
Bridge to processor
mechanical interface.
Figure 8.3. Cutaway view showing key parts of the media path through the bridge.
Avantra 20/25 OLP Bridge Operation • 8–9
