Figure 3.8. The four Imaging modes are listed left to right.
You change imaging mode in the Configuration Screen.
—Positive right reading.
—Negative right reading.
The three media types are listed top to bottom.
You change media type in the Cassette Screen.
Figure 3.9. Cassette number. Adjust in Cassette Screen.
3–10 • SelectSet Avantra User Guide
A.
B.
C.
A—Film. B—Paper. C—Plate.
—Positive wrong reading.
—Negative wrong reading.
