Feed Amounts, continued...

Definitions

Feed Amount: Media fed when you use Feed in the Utilities Screen or
when you send a feed command from your front end.
Feed and Cut Amount: Media fed between most recent job and a cut.
Used by Feed and Cut in the Pause Screen.
Interpage Spacing: Media fed between jobs.
Supply Alarm Amount: When the amount of media remaining in a
supply cassette is less than this amount, an alarm appears.
Take-up Alarm Amount: When the amount of media fed into the take-
up cassette is greater than this amount, an alarm appears.
Distance to Punches: Distance from the center of the top punches to
the leading edge of the image.
Supply Alarm
Take-up Alarm
Distance to Punches
Range:
0.0 to 250.0 ft
0.0 to 76.2 m
Range:
0.0 to 100.0 ft
0.0 to 30.5 m
Range:
0.48 to 10 in.
12 to 254 mm
Using the Control Panel • 3–23
