53 Bridge Jam At Processor Entry
Open the media compartment and remove the top bridge
cover.
Look for media caught near the entry to the media pro-
cessor. See Figures 6.2 and 6.3.
54 Bridge Jam After Center Sensor
Open the media compartment and remove the top bridge
cover.
Look for media caught on the top section of the bridge.
See Figures 6.2 and 6.3.
55 Bridge Motor Jammed
Open the media compartment and remove the top and
bottom bridge covers.
Media could be caught anywhere on the bridge. See Fig-
ures 6.2 and 6.3.
56 No Response, Bridge Entry Sensor
Open the media compartment and lift the bridge up out of
the way.
Look for media protruding from the media slot. See Fig-
ures 6.2 and 6.3.
If you find no media, remove the nip drive assembly. (This
procedure is described in the section Clearing Media Jams
in chapter 7.)
Diagnostics and Error Messages • 6–11
