Note these tips when you use this feature:
• If a top bar is imaged, imaging time for a page is longer.
• If you need more exposed plate material, specify a larger page size
through your front end application. See Figure C.3.
• Do not advance more than 90' (27.4 m) of Setprint HN LL 5 mil plate
material into the take-up cassette.
• Do not advance more than 56' (17 m) of Setprint HN LL 8 mil plate
material into the take-up cassette.
• Maximum image depth may be reduced. See Figure C.4. The gray
bands show where the page may be clipped.
The top bar may overlap the top of your page by up to
If the page depth plus the top bar depth is greater than the drum
length (22" or 55.8 cm), the top bar may overlap the bottom of the
preceding page by up to
B–4 • SelectSet Avantra User Guide
/ " (.7 cm).
1
4
/ " (.7 cm).
1
4
