Clearing the Bridge Media Path

The bridge is covered by two access panels. You can take these panels
off to reach the bridge media path.
Sensors in the bridge monitor the position of a piece of media as it trav-
els through the bridge. If the sensors detect a media jam, the error
message that appears on the imagesetter control panel helps you de-
termine where to look to clear the problem.

Removing the Bridge Access Panels

• The bridge has two access panels.
• Both are held in place by four screws. The screws are attached so
that they cannot fall out of the panel when they have been loosened.
• The panels interlock. You need to remove the top panel before you
can remove the lower panel.
• Rollers inside the bridge guide the media.
• These rollers can move in one direction only—toward the processor.
Keep this in mind if you are about to pull a piece of media out of the
bridge.
8–8 • SelectSet Avantra User Guide
