To Use Utilities Functions

1. Select a function.
For example, press cut.
2. Press Accept.
Press once and the icon
flashes.

Definitions

Retract Punches and Nips: Rollers called nip rollers and punches hold
media in place. Press Retract Punches and Nips to release media. Use
when clearing jams.
Cut: Cuts media with no media feed. Before the imagesetter makes the
cut, it checks to make sure that at least 6" (15.3 cm) has been fed past
the cutter. This prevents you from cutting a short piece of media that
could slip between the feed rollers and cause a jam.
Feed: Feeds the amount of media specified by Feed Amount in the
Feed Amounts Screen.
Reverse Feed: Use to unload media when a media jam or carriage jam
prevents you from using Unload in the Pause Screen. Rewinds media
into the supply cassette without making a Feed and Cut and without
centering the media shields in the drum. If there is media in the take-
up cassette, press Cut before Reverse Feed.
Switch Supplies: On imagesetters with the DualSupply option, use
when supply rollers are not set to the correct position for the supply
that you want to load or remove.
Press again to confirm or...
...press Abort to cancel.
Using the Control Panel • 3–25
