Run and Pause Status Icons

This section describes status icons that appear in the Run Screen and
the Pause Screen.
Figure 3.3. The Run Screen (left) and the Pause Screen (right).
—Media status, supply B (appears only with DualSupply Option).

Media Status

—Media width.
—Media type, alignment mode, imaging mode.
3–8 • SelectSet Avantra User Guide
—Media status, supply A.
—Engine status.
Figure 3.4. The media status display.
—Top punch. —Bottom punch.
—Job status.
—Media remaining.
—Cassette number.
