Figure 3.5. The display changes to show that a media supply is loaded.
Left, DualSupply A loaded. Right, DualSupply B loaded.
Figure 3.6. Punch modes. Adjust in Cassette Screen.
These symbols are used as a convention to represent the many different
punch configurations that are available.
—Punches off. —Top punches on. —Bottom punches on.
—Top and bottom punches on.
Figure 3.7. Alignment mode. Adjust in Configuration Screen.
—Flush left. —Centered.
Using the Control Panel • 3–9
