Clear Media from Input Side

Step 1: Turn off the imagesetter.
Step 2: Raise the top cover.
• If your imagesetter is equipped with an on-line bridge, lift
the bridge up and out of the way.
Step 3: Remove the plastic light shield that covers the front of the
media supply area.
• The light shield pivots on two metal pins in the media
compartment. Raise the light shield.
• There is an open slot in the light shield at the left pivot
point. Raise the shield so that this opening lines up with
the flat sides of the metal pin.
• Lift the left side of the light shield up and off the left pin,
then slide the right side off the right pin.
Step 4: Remove the light shield that covers the rear of the media
supply area.
• Lift it straight up and out of the imagesetter.
Step 5: Remove the light shield that covers the media path.
• Loosen the six latches that hold the shield in place.
• There is a handle in the center of the shield.
• Hold the shield by the handle and slide it up toward the
top of the imagesetter.
• Lift the shield so the bottom is free, then slide the shield
down to free the top edge.
• Lift the light shield out of the imagesetter and move it out
of the way.
Step 6: Clear the media path.
Step 7: Replace the media path light shield. Be sure to tighten all six
latches that hold the light shield in place.
Maintenance and Troubleshooting • 7–9
