Figure 4.3. Remove the endcaps.
Step 2. Adjust the endcaps to match the media width.
Loosen the small locking knob. If necessary, use the special
wrench supplied with the imagesetter to loosen the knob.
Figure 4.4. Loosen the small locking knob . Use the wrench if necessary.
Slide the shaft to adjust. It will click into place. Markings in-
dicate the correct position for various media widths.
Figure 4.5. Adjust the position of the shaft.
Hold the endcap by the outer locking knob and tighten the
small locking knob.
Note: If you are reloading the supply cassette with
the same width media, check to make sure that
the endcaps are still set correctly.
Media Operations • 4–3
