SnapServer 7.0 Administrator's Guide
The following table shows details about member drives of that specific RAID:
Label
RAID Set
Status
Group
Size
Unallocated
CAUTION:
data before making changes to RAID sets.
From this secondary page, you can:
• Remove an individual RAID disk drive or local spare.
• Add a disk drive.
• Delete the entire RAID set (if not part of a group).
To Remove a RAID Drive
From the RAID Set Properties page, you can remove a RAID disk drive or local spare by
clicking the Action link on the far right of disk table. If you are removing primary RAID
disk, you will see a message page warning of RAID running in a degraded mode (no or
reduced parity).
NOTE: The only types of drives that can be removed are local spares, members of a mirror, and
To Add a Disk Drive to RAID
Clicking the Add Disk button at the bottom of the page displays a table of available disk
drives. Check one or more of the boxes to add them to the RAID set and click Next for the
confirmation page.
10400317-001 10/2011
Description
The name of each RAID.
The current condition of the RAID:
• OK – The RAID is functioning properly.
• OK–Spare Missing – The RAID is functioning properly after a
repair and rebuild. Because the local spare was consumed to
repair the RAID, it is no longer available as a spare.
It is recommended that the original drive that failed be
replaced to restore the RAID to its proper configuration and
provide the full protection by one or more local spares.
Alternately, you can click the link to reset the RAID spare count;
however, the RAID will not be able to automatically recover from
a drive failure.
• Resync – A device repair operation is in progress.
• Failed – The RAID is offline.
• Degraded – A drive has failed or been removed.
Number of members in the RAID:
• Active – Number of non-spare disks in the RAID that have a
status of OK.
• Configured – Number of non-spare disks with which the RAID
was configured.
The name of the RAID Group to which the RAID belongs.
The total capacity of the RAID.
The total storage space not allocated to a volume.
Actions on this page can result in a loss of data. Be sure you have backed up your
failed drives.
©2010-11 Overland Storage, Inc.
5 – Traditional RAID Storage
5-11
