Appendix C
Basic techniques for identifying and resolving common hardware and networking issues are
described here.
Topics in Troubleshooting SnapServers
•

LED Indicator Meanings

•

System Reset Options

• Maintenance Mode
• Networking Issues
•
Miscellaneous Issues
• Phone Home Support
LED Indicator Meanings
LED indicators provide information on the status of basic connectivity, disk drives, fan
modules, and power supply modules.

SnapServer DX1

The SnapServer DX1 has two Network lights (Ethernet 1, left; Ethernet 2, right), one power
light, one status light, and two disk lights per disk drive, as shown in the following
illustration.
10400317-001 10/2011
Troubleshooting SnapServers
Drive Activity Drive Status
©2010-11 Overland Storage, Inc.
Ethernet 1 Ethernet 2 Status
C-1
