5.4.11 REMOTE (J20)

The Remote Port is a RS-485 or RS-232 Connection for remote monitor and control of the
modem. It is a 9-Pin Female "D" Connector. Refer to Table 5-5 for pinouts.
Table 5-5. Remote Port (RS-485 or RS-232) 9-Pin Female "D" Connector (J20)
Pin No.
1
2
3
4
5
6
7
8
9
When operating the remote port as RS232 using a cable pinned 1 for 1 may
cause communication failures due to miss routing of standard RS232 com
port signals.
When operating the remote port as RS232, the cable used should only have
pins 2, 3 and 5 connected.

5.4.12 ETHERNET (J21)

The ETHERNET Port (J21) can be used for the Monitor & Control (M&C) Functions of the unit.
The physical interface is a standard female RJ-45 Connector.
5.5 G.703 IDR/IBS Interface (Optional)
The DMD50 supports two versions of the G703 IDR/IBS interface.
Interface options are G703 T1/E1/T2/E2 or G703 T1/E1/T2/E2/E3/T3 and STS1.
MN-DMD50– Revision 3
Signal Name
Transmit Data RS-485 (+)
Transmit Data RS-232
Receive Data RS-232
NC
Ground
Transmit Data RS-485 (–)
NC
Receive Data RS-485 (+)
Receive Data RS-485 (–)
Signal Direction
TX-485-B Output
TXD-232 Output
RXD-232
NC
GND
TX-485-A Output
No Connection
RX-485-B/CTS
RX-485-A
User Interfaces
Input
---
---
---
Input
Input
