DMD50 Universal Satellite Modem
INSTALLED indicates that the option is already available as part of the modems feature set.
HW & KEY REQ indicates that additional hardware is required to support the option. Contact
your Radyne sales representative for more information regarding the required hardware upgrade.
KEY CODE REQ indicates that the desired option can be enabled as a demonstration from the
front panel.
2. Contact Radyne with the Unit ID and Request a Demonstration.
The modem's Unit ID can be found on the front panel as follows:
a. From the modem's Main Menu, scroll right to the SYSTEM Menu.
b. Scroll down.
c. Scroll right to the HW/FW CONFIG Menu.
d. Scroll down.
e. Scroll right to the FEATURES Menu.
f. Scroll down.
The value displayed on the top line of this menu is the 12-digit Unit ID. It is displayed as on the
front panel of the modem as 3 sets of 4 digits in a dot-delineated format as follows:
1 2 3 4 . 1 2 3 4 . 1 2 3 4
Your Radyne sales representative will ask you for this number along with the features you wish
to demo.
3. Once your order has been processed, you will be issued a 12-digit demonstration code. This
code can only be used one time and it is only good on the modem for which it was originally
requested. To enter this code from the front panel, perform the following:
a. From the modem's Main Menu, scroll right to the SYSTEM Menu.
b. Scroll down.
c. Scroll right to the HW/FW CONFIG Menu.
d. Scroll down.
e. Scroll right to the FEATURES Menu.
f. Scroll down.
The value displayed on the top line of this menu is the 12-digit Unit ID. It is displayed on the
front panel of the modem as 3 sets of 4 digits. The second line is the data entry area and is
displayed as 3 sets of 4 underscores in a dot-delineated format.
Press <ENTER> and a cursor will begin flashing in the data entry area
Using the numeric keypad, enter your 12-digit demonstration code
Press <ENTER>.
If the code entered is correct, the display will display CODE ACCEPTED, otherwise the display
will read INVALID CODE.
MN-DMD50– Revision 3
Front Panel Upgrade Procedure
B–4
