DMD50 Universal Satellite Modem

5.13 ASI/DVB/M2P Interface (Optional)

5.13.1 ASI IN (J1)

The ASI IN Port (J1) is supported on the BNC Connector. The interface complies with DVB ASI
Electrical Specifications.

5.13.2 ASI OUT (J2)

The ASI OUT Port (J2) is supported on the BNC Connector. The interface complies with DVB
ASI Electrical Specifications.

5.13.3 DVB/M2P IN (J3)

DVB or M2P IN Port (J3) is supported on the DB-25 female connector. It complies with RS-422
Electrical Specifications. Refer to Table 5-13 for DVB and Table 5-14 for M2P pinouts for this
connector.
MN-DMD50– Revision 3
User Interfaces
5–15
