DMD50 Universal Satellite Modem
STRAP CODE
MN-DMD50– Revision 3
Data rates not covered by a given mode will not be allowed. If
the mode of operation is selected after the data rate has been
entered, then the data rate must be compatible with the desired
mode of operation or the Network Spec will not be allowed. The
following parameters cannot be changed while the unit is in the
given mode of operation:
IDR:
(IESS-308)
For Data rates 1.544, 2.048, 6.312, 8.448 Mbps
Framing Type:
Descrambler type:
Spectrum Mask:
For Data Rates < 1.544 Mbps
Framing Type:
Descrambler Type:
Spectrum Mask:
IBS:
(IESS-309)
For Data Rates < 2.048 Mbps
Framing Type:
Descrambler Type:
Spectrum Mask:
Drop & Insert:
Data Rates:
Framing Type:
Descrambler Type:
Spectrum Mask:
Efficient D&I
Data Rates:
Descrambler Type:
Spectrum Mask:
DVB: Per EN301-421 & En301-210
Data Rates:
Framing Type:
Spectrum Mask:
Closed Net:
All possible combinations allowed, however, DVB settings
requires the DVB network spec.
{Refer to Strap Code Guide, Appendix D}
96 Kbps (IDR)
V.35
Intelsat
1/15 (IBS)
IESS-309
Intelsat
1/15 (IBS)
IESS-309
Intelsat
n x 64, n = 1, 2, 3, 4, 5, 6, 8, 10, 12, 15,
16, 20, 24, 30
1/15 (IBS)
IESS-309
Intelsat
Closed Network,
n x 64, 1-31 Any combination
IESS-309
Intelsat
All Rates
DVB
Scrambler Type:
DVB 0.25, 0.35
User Interfaces
DVB
4–12
