5.17 Ethernet Data Interface

The DMD50 Ethernet Data Interface provides four RJ-45, Auto-Crossover and Auto-Sensing,
10/100 Ethernet Data Ports. JS1 through JS4 may be referred to Port 1 through Port 4
respectively. Refer to Figure 5-1 for rear panel configurations.
•
JS1 is Port 1
•
JS2 is Port 2
•
JS3 is Port 3
•
JS4 is Port 4
Refer to Figure 5-1 for outline and Appendix I for setup & configuration.

5.18 GigE Interface

The optional Ethernet Data Interface provides a three port RJ45 10/100/1000 Base-T Interface.
The Ethernet interface supports Auto-Crossover and Auto-Sensing. The Ethernet port are
referred to as JS1 through JS4 or JS1 through JS3. Refer to Figures 5-1 for rear panel
configurations.
JS1 is Port 1
JS2 is Port 2
JS3 is Port 3
Refer to Figure 5-1 for outline.
