D.1

Introduction

The DMD20/50/2050 Web Browser allows for connection to Radyne products through the
Ethernet port. The Web interface allows for complete control and monitoring of all equipment
parameters and functions via a 10Base-T Ethernet connection. Utilization of the Web browser is
dependent upon proper set-up of the TCP-IP menus. For TCP-IP setup guidelines refer to
Appendix G in the manual. For additional information on the various WEB configurations and
descriptions refer to the Remote Protocol Manual MN-DMDREMOTEOP.
To verify that the Radyne product is configured with the Web interface, use the products front
panel <SYSTEM> control screen and verify that the WEB sub menu is visible. Contact the
Radyne Customer Service Department if the WEB feature is not displayed on the front panel to
identify the product is upgradeable.
Utilization of the Web Browser requires proper setup of the TCP-IP menus. The unit is
shipped from the factory with the Boot Mode configured as Default. Verify that the
Boot Mode is set for Default. To access the unit via the Ethernet port, set the Boot
Mode to IP TEST. This will set the IP parameter to an accessible address. If user
wants to utilize an alternate address, user must set the Boot Mode to NON-VOL.
Contact the IT manager for proper guidance to ensure setup is successful.
MN-DMD50– Revision 3
Appendix D. Web Browser
IMPORTANT
Setup Guide
D–1
