DMD50 Universal Satellite Modem
LED TEST
REMOTE CONTROL
TERMINAL (menu)
TYPE
BAUD RATE
REMOTE PORT (menu)
ADDRESS
BAUD RATE
INTERFACE
TCP/IP (menu)
BOOT MODE
MN-DMD50– Revision 3
{ENTER}
Allows user to test all front panel LEDs.
{TERMINAL, COMPUTER}
Allows the user to select between terminal RS-232 control and
remote port M&C RS-232/-485 control.
{VT-100, WYSE50, VIEWPOINT}
Allows the user to select the emulation type.
{300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600}
Allows the user to enter the terminal baud rate.
{32 - 255}
Allows the user to enter the Remote Port Multidrop Address.
{300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600}
Allows the user to enter the Remote Port Baud Rate.
{RS-232, RS-485}
Allows the user to enter the Remote Port interface type.
{DEFAULT, NON-VOL, BOOTP, IP TEST}
DEFAULT : During initialization (boot up), the modem will restore the web
setting to the standard IP Mask and addresses supplied by the modem. The
modem will be taken off the network and will not be accessible. The Default
settings are:
IP Address Mask:
Modem IP Address:
Server IP Address:
Router IP Address:
BOOTP : During initialization (boot up), the modem will get the
names, masks, and IP Addresses of the modem, router,
and server.
NON-VOL: Stores and uses IP Mask and addresses as provided by
the user.
255.000.000.000
010.000.000.001
010.001.001.001
010.000.001.001
User Interfaces
(FF.00.00.00 hex)
(C0.A8.00.EE hex)
(0A.01.01.01 hex)
(0A.00.01.01 hex)
4–33
