DMD50 Universal Satellite Modem
Items that do not have ID numbers are Status only and cannot be changed.
4.7

Connecting the Terminal

1. Connect the computer to the Remote Connector (J20) on the rear of the unit using the RS-
232 Cable.
2. Enable the terminal by selecting Terminal Mode (located under the System - Control
Mode Menu) from the front panel.
3. Verify that your emulation software is set to the following:
8 data bits
no parity
1 stop bit
Modify the selection, if necessary, to match the settings (the Front Panel 'SYSTEM' Sub-
Menu contains all the Terminal Emulation Controls).
MN-DMD50– Revision 3
User Interfaces
4–44
