Comtech EF Data DMD50 Installation And Operation Manual page 108

DMD50 Universal Satellite Modem
Masking alarms may cause undesirable modem performance.
CURRENT ALARMS (menu)
FPGA CFG
DSP CFG
SCT CLOCK PLL
SYM CLOCK PLL
LB SYNTH PLL
IF SYNTH PLL
ETHERNET WAN
FORCED ALARM
TX MINOR (menu)
MN-DMD50– Revision 3
TX MAJOR (menu)Status
{Pass/Fail, Unmasked/Masked}
Indicates a transmit FPGA configuration failure.
{Pass/Fail, Unmasked/Masked}
Indicates a transmit DSP configuration failure.
{Pass/Fail, Unmasked/Masked}
Indicates that the Tx SCT Clock PLL is not locked. This alarm
will flash on during certain modem parameter changes. A solid
indication points toward a configuration failure within the
modem.
{Pass/Fail, Unmasked/Masked}
Indicates that the Tx Symbol Clock PLL is not locked. This
alarm will flash on during certain modem parameter changes. A
solid indication points toward a problem with the incoming clock
to the modem (SCTE).
{Pass/Fail, Unmasked/Masked}
Indicates that the Tx L-Band Synthesizer is not locked. This
alarm will flash on during certain modem parameter changes. A
solid indication points toward a configuration problem within the
modem.
{Pass/Fail, Unmasked/Masked}
Indicates that the Tx IF Synthesizer is not locked. This alarm
will flash on during certain modem parameter changes. A solid
indication points toward a configuration problem within the
modem.
{Pass/Fail, Unmasked/Masked}
Indicates that the interface card is faulted and will not pass data
(displays only when the Ethernet Card is installed and the
Ethernet Interface is selected).
{DISABLED, ENABLED}
Allows user to disable or enable forcing of a Tx Summary
Alarm.
Edit Table
User Interfaces
4–24
