DMD50 Universal Satellite Modem
9 Receive Timing B (+)
10 Receiver Ready B (+)
11 Terminal Timing B (+)
12 Send Timing B (+)
13 Clear T Send B (+)
14 Send Data B (+)
15 Send Timing A (-)
16 Receive Data B (+)
17 Receive Timing A (-)
18 Modulator Fault - Open Collector
19 Request To Send B (+)
20 Data Terminal Ready A (-)
21 Demodulator Fault
22 Data Mode B (+)
23 Data Terminal Ready B (+)
24 Terminal Timing A (-)
25 No Connection
MN-DMD50– Revision 3
RT-B
RR-B
TT-B
ST-B
CS-B
SD-B
ST-A
RD-B
RT-A
MF
RS-B
TR-A
DF
DM-B
TR-B
TT-A
---
User Interfaces
Output
Output
Input
Output
Output
Input
Output
Output
Output
Output
Input
Input
Output
Output
Input
Input
---
