DMD50 Universal Satellite Modem
HW/FW CONFIG (menu)
FIRMWARE REV
M&C REV
MAIN BOARD (menu)
Only the appropriate of the VCO adjustment screens listed below will be
displayed. These are protected fields, to prohibit accidental changes. To edit
the field, the user must depress all four of the direction arrow keys
simultaneously.
INT VCO ADJUST
HI STAB VCO ADJUST
LARGEST HB GAP Used for factory test only.
SOFT RESET
IF BOARD (menu)
AGC/CTRL/VALUE {0% - 100%}
I OFFSET
Q OFFSET
IF RX LVL OFFSET Used for factory test only.
LB RX LVL OFFSET Used for factory test only.
POWER SOURCE
MN-DMD50– Revision 3
Displays the installed firmware revision.
Displays the installed Monitor and Control revision.
{0% - 100%}
Allows the user to adjust the internal frequency reference for
calibration. Only displayed of the system reference clock is
INTERNAL.
{0% - 100%}
Allows the user to adjust the internal frequency reference for
calibration. Only displayed if the system reference clock
source is HI STABILITY.
{Enter}
Indicates the Radyne part number for the IF Board Assembly.
Allows the user to adjust the internal frequency reference for
calibration. Only displayed if the system reference clock
source is HI STABILITY.
Used for factory test only.
Used for factory test only.
Used for factory test only.
User Interfaces
