Comtech EF Data DMD50 Installation And Operation Manual page 146

DMD50 Universal Satellite Modem
Table 5-13. J3 − DVB In - 25-Pin Female
Pin Number Signal Name
1 CLK+
14 CLK-
SYSTEM
2
GND
SYSTEM
15
GND
3 D7+
16 D7-
4 D6+
17 D6-
5 D5+
18 D5-
6 D4+
19 D4-
7 D3+
20 D3-
8 D2+
21 D2-
9 D1+
22 D1-
10 D0+
23 D0-
11 DVALID+
24 DVALID-
12 PSYNC+
25 PSYNC-
13 Cable Shield
MN-DMD50– Revision 3
Table 5-14. J3 − M2P In - 25-Pin Female
Direction
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
---
Pin Number Signal Name
1 OUTCLK+
14 OUTCLK-
2 CLK+
15 CLK-
3 SYNC+
16 SYNC-
4 VALID+
17 VALID-
5 D0+
18 D0-
6 D1+
19 D1-
7 D2+
20 D2-
8 D3+
21 D3-
9 D4+
22 D4-
10 D5+
23 D5-
11 D6+
24 D6-
12 D7+
25 D7-
13 Cable Shield
User Interfaces
Direction
Output
Output
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
Input
---
5–16
