DMD50 Universal Satellite Modem
TERR INTFC BRD
CODEC BOARD (menu)
TPC FPGA IMAGE
RS FPGA IMAGE
TPC CODEC IMAGE Used for factory test only.
FRONT PANEL BOARD
FEATURES (menu)
5012.2840.2417
UPGRADE LIST (menu)
MN-DMD50– Revision 3
Indicates the Radyne assembly number for the Terrestrial
Interface Assembly.
Indicates the Radyne part number for the Codec Board.
Used for factory test only.
Used for factory test only.
Indicates the Radyne assembly number for the front panel board.
{____.____.____}
Allows the user to install purchased feature upgrades (see
Appendix A).
Contact the ustomer Service Department or Sales for hardware
and software upgrades.
10 MBPS, 20 MBPS, 52 MBPS (The highest option installed will hide the lower
rates.)
RXIF
RXLBAND
TXIF
TXLBAND
ENH ASYNC
IDR
SEQ
RS
RS CUSTOM
IBS
D&I
AUPC
8PSK
The following identifies the available upgrade features:
User Interfaces
4–40
