DMD50 Universal Satellite Modem
G.703 E2
G.703 E3
G.703 T3
G.703 STS1

7.18 HSSI /ETHERNET

HSSI
Connector (Female)
Ethernet Data Interface

7.19 Environmental

Prime Power
Operating Temperature
Storage Temperature

7.20 Physical

Size
Weight
MN-DMD50– Revision 3
8.448 Mbps, 75-Ohm BNC, Unbalanced, HDB3
34.368 Mbps, 75-Ohm BNC, Unbalanced
44.736 Mbps, 75-Ohm BNC, Unbalanced
51.84Mbps, 75-Ohm BNC, Unbalanced
Note: Does not support backward alarms
HSSI, High-Speed Serial Interface, 50-pin SCSI-2 Type
Four RJ-45, Auto-Crossover, Auto-Sensing, 10/100 Ethernet
Data Ports. Complies with IEEE 802.3 and IEEE 802.3u.
100 to 240 VAC, 50 to 60 Hz, 250 Watts Maximum
48 VDC (Optional)
-10 to +60°C, 95% Humidity, Non-Condensing
-20 to 70°C, 99% humidity, Non-Condensing
19" W x 19.25" D x 1.75" H
(48.26 x 48.89 x 4.45 cm)
6.5 Pounds (3.0 Kg)
Technical Specifications
7–5
