G.703 T3
G.703 STS1

7.10 IBS/Synchronous Interface (Standard)

MIL-188-144A/RS-422/-530
ITU V.35
RS-232

7.11 High-Speed Serial Interface (HSSI)

HSSI:

7.12 ASI

ASI:
RS-422 Parallel:
ASI:
LVDS Parallel:

7.13 DVB/M2P

DVB/M2P:

7.14 Ethernet Data Interface (Optional)

Ethernet Data Interface

7.15 Gigi Ethernet Data Interface (Optional)

Ethernet Data Interface

7.16 HSSI / G703 T2/E2 Max

HSSI
G.703 T1 (DSX1)
G.703 E1
G.703 T2 (DSX2)
G.703 E2

7.17 HSSI / G703 T3/E3/STS1 Max

HSSI
G.703 T1 (DSX1)
G.703 E1
G.703 T2 (DSX2)
MN-DMD50– Revision 3
44.736 Mbps, 75-Ohm BNC, Unbalanced
51.84Mbps, 75-Ohm BNC, Unbalanced
All Rates, Differential, Clock/Data, DCE
All Rates, Differential, Clock/Data, DCE
(DCE up to 200 Kbps)
HSSI, Serial, 50-Pin SCSI-2 Type Connector (Female)
ASI, Serial, 75 Ohm BNC (Female)
DVB/M2P, Parallel, RS-422, DB-25 (Female)
ASI, Serial, 75 Ohm BNC (Female)
DVB/M2P, Parallel, LVDS, DB-25 (Female)
DB-25 Female Connector. It complies with RS-422 Electrical
Specifications.
Four RJ-45, Auto-Crossover, Auto-Sensing, 10/100 Ethernet
Data Ports. Complies with IEEE 802.3 and IEEE 802.3u.
Three RJ-45, Auto-Crossover, Auto-Sensing, 10/100/1000
Ethernet Data Ports. Complies with IEEE 802.3 and IEEE
802.3u.
High-Speed Serial Interface, 50-pin SCSI-2 Type Connector
(Female)
1.544 Mbps, 100-Ohm Balanced, AMI and B8ZS
2.048 Mbps, 75-Ohm Unbalanced and 120-Ohm Balanced,
HDB3
6.312 Mbps, 75-Ohm Unbalanced and 110-Ohm Balanced,
B8ZS and B6ZS
8.448 Mbps, 75-Ohm BNC, Unbalanced, HDB3
Note: Does not support backward alarms
High-Speed Serial Interface, 50-pin SCSI-2 Type Connector
(Female)
1.544 Mbps, 100-Ohm Balanced, AMI and B8ZS
2.048 Mbps, 75-Ohm Unbalanced and 120-Ohm Balanced,
HDB3
6.312 Mbps, 75-Ohm Unbalanced and 110-Ohm Balanced,
B8ZS and B6ZS
Technical Specifications
7–4
