xStack
Pool Name This field will denote the Pool Name of the displayed dynamically bound DHCP entry.
IP Address This field will display the IP address allotted to this device by the DHCP Server feature of this
Switch.
This field will display the MAC address of the device that is bound to the corresponding IP address.
Hardware
Address
This field will display the type of node server being used for the previously configured Net BIOS
Type
Name server of this entry.
This field will display the Status of the entry, whether it was dynamically bound or manually bound.
Status
Life Time (sec) This field will display, in seconds, the time remaining on the lease for this IP address.

DHCP Server Manual Binding

The following windows will allow users to view and set manual DHCP entries. Manual DHCP entries will bind an IP address with
the MAC address of a client within a DHCP pool. These entries are necessary for special devices on the local network that will
always require a static IP address that cannot be changed.
To view this window, click Administration > DHCP Server > DHCP Server Manual Binding, as shown below:
Users may view statically bound DHCP entries within a DHCP pool by entering the Pool Name and clicking Find. Results will be
displayed in the window above. To set a manual DHCP Binding entry, click the Add window, which will produce the following
window to configure.
The following parameters may be configured or viewed.
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
Figure 2 - 65 DHCP Server Manual Binding Table window
Figure 2 - 66 Create DHCP Pool Manual Binding window
