The following fields can be set or modified:
Parameter
IP Address
MAC Address
Ports
Click Add to create a new entry, click Find to search for an entry, click View All to display all entries, and click Delete All to
remove all entries on the window.

DHCP Snooping Entries

This window is used to view DHCP Snooping entries on specific ports.
To view this window, click Security > IP-MAC-Port Binding > DHCP Snooping Entries, as shown below:
To view particular port settings, enter the port number and click Find. To view all entries on the window, click View All, and to
delete an entry, click Clear.

MAC Block List

This window is used to view unauthorized devices that have been blocked by IP-MAC binding restrictions.
To view this window, click Security > IP-MAC-Port Binding > MAC Block List, as shown below:
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
Figure 6 - 7 IMP Entry Settings window
Description
Enter the IP address to bind to the MAC address set below.
Enter the MAC address to bind to the IP Address set above.
Specify the switch ports for which to configure this IP-MAC binding entry (IP Address + MAC
Address). Tick the All Ports check box to configure this entry for all ports on the Switch.
Figure 6 - 8 DHCP Snooping Entries window
