Authentication Server Group - D-Link xStack User Manual

xStack
The following parameters can be set:
Parameter
Application
Login Method List
Enable Method List
Click Apply to implement changes made.

Authentication Server Group

This window will allow users to set up Authentication Server Groups on the Switch. A server group is a technique used to group
TACACS/XTACACS/TACACS+/RADIUS server hosts into user-defined categories for authentication using method lists. The
user may define the type of server group by protocol or by previously defined server group. The Switch has three built-in
Authentication Server Groups that cannot be removed but can be modified. Up to eight authentication server hosts may be added
to any particular group.
To view this window, click Security > Access Authentication Control > Authentication Server Group, as shown below:
This window displays the Authentication Server Groups on the Switch. The Switch has four built-in Authentication Server Groups
that cannot be removed but can be modified. To modify a particular group, click its hyperlinked Group Name, which will then
display the following window.
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
Description
Lists the configuration applications on the Switch. The user may configure the Login Method
List and Enable Method List for authentication for users utilizing the Console (Command Line
Interface) application, the Telnet application, SSH and the Web (HTTP) application.
Using the pull-down menu, configure an application for normal login on the user level,
utilizing a previously configured method list. The user may use the default Method List or
other Method List configured by the user. See the Login Method Lists window, in this section,
for more information.
Using the pull-down menu, configure an application for normal login on the user level,
utilizing a previously configured method list. The user may use the default Method List or
other Method List configured by the user. See the Enable Method Lists window, in this
section, for more information
Figure 6 - 37 Authentication Server Group window
254
