xStack
Parameter
Device Name
Local Port
Speed
Remote Port
MAC Address
Model Name
To view the Topology Map, click the View menu in the toolbar and then Topology, which will produce the following screen. The
Topology View will refresh itself periodically (20 seconds by default).
This screen will display how the devices within the Single IP Management Group connect to other groups and devices. Possible
icons in this screen are as follows:
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
Description
This field will display the Device Name of the switches in the SIM group configured by the user.
If no device is configured by the name, it will be given the name default and tagged with the
last six digits of the MAC Address to identify it.
Displays the number of the physical port on the CS that the MS or CaS is connected to. The
CS will have no entry in this field.
Displays the connection speed between the CS and the MS or CaS.
Displays the number of the physical port on the MS or CaS to which the CS is connected. The
CS will have no entry in this field.
Displays the MAC Address of the corresponding Switch.
Displays the full Model Name of the corresponding Switch.
Figure 2 - 104 Topology view
