xStack DGS-3200 Series Layer 2 Managed Gigabit Ethernet Switch Web UI Reference Guide
Next Server
DNS Server Address
NetBIOS Name
Server
Default Router
Pool Lease
Click the Apply button to accept the changes made. Click the <<Back button to discard the changes made and return to the
previous page.

DHCP Server Manual Binding

An address binding is a mapping between the IP address and MAC address of a client. The IP address of a client can be assigned
manually by an administrator or assigned automatically from a pool by a DHCP server. The dynamic binding entry will be created
when an IP address is assigned to the client from the pool network's address.
To view the following window, click Network Application > DHCP Server > DHCP Server Manual Binding:
The following parameters may be configured:
Parameter
Pool Name
IP Address
Hardware Address
Type
Click the Add button to add a new entry based on the information entered. Click the Delete All button to remove all the entries
listed. Click the Delete button to remove the specific entry.
the same pool, the second command will overwrite the first command. If the boot file is not
specified, the boot file information will not be provided to the client.
Enter the next server IP address.
IP address of DNS server. Specifies the IP address of a DNS server that is available to a
DHCP client. Up to three IP addresses can be specified in one command line.
IP address of WINS server. Windows Internet Naming Service (WINS) is a name resolution
service that Microsoft DHCP clients use to correlate host names to IP addresses within a
general grouping of networks. Up to three IP addresses can be specified in one command
line.
IP address of default router. Specifies the IP address of the default router for a DHCP client.
Up to three IP addresses can be specified in one command line.
By default, each IP address assigned by a DHCP server comes with a one-day lease, which
is the amount of time that the address is valid. Tick the Infinite check box to have infinite
lease.
Days – Days of lease.
Hours – Hours of lease.
Minutes – Minutes of lease
Figure 8 - 10. DHCP Server Manual Binding window
Description
Enter the DHCP Server Pool name.
IP address which will be assigned to specified client.
Enter the hardware address.
Either Ethernet or IEEE802 can be specified.
237
