xStack
TxPeriod(1-65535)
QuietPeriod(0-
65535)
SuppTimeout(1-
65535)
ServerTimeout(1-
65535)
MaxReq(1-10)
ReAuthPeriod(1-
65535)
MaxUser(1-128)
ReAuth
Forward EAPOL
PDU
Capability
Click Apply to implement your configuration changes. To view configurations for the 802.1X Authenticator Settings on a port-
by-port basis, see the 802.1X Authenticator Settings table.
®
DGS-3400 Series Layer 2 Gigabit Ethernet Managed Switch
The default setting is Auto.
This sets the TxPeriod of time for the authenticator PAE state machine. This value determines
the period of an EAP Request/Identity packet transmitted to the client. The default setting is 30
seconds.
This allows the user to set the number of seconds that the Switch remains in the quiet state
following a failed authentication exchange with the client. The default setting is 60 seconds.
This value determines timeout conditions in the exchanges between the Authenticator and the
client. The default setting is 30 seconds.
This value determines timeout conditions in the exchanges between the Authenticator and the
authentication server. The default setting is 30 seconds.
The maximum number of times that the Switch will retransmit an EAP Request to the client
before it times out of the authentication sessions. The default setting is 2.
A constant that defines a nonzero number of seconds between periodic reauthentication of the
client. The default setting is 3600 seconds.
The maximum number of users for each port that can be learned via 802.1X authentication.
Determines whether regular reauthentication will take place on this port. The default setting is
Disabled.
This enables or disables the Switch retransmit EAPOL PDU Request on a per port basis.
This allows the 802.1X Authenticator settings to be applied on a per-port basis. Select
Authenticator to apply the settings to the port. When the setting is activated, a user must pass
the authentication process to gain access to the network. Select None disable 802.1X functions
on the port.
