Page 1 Statistics Reference for the Versalar Switch Router 15000 Carrier Networking Services V15K_1.3.0.0 Part No. 308689-B Rev 00 March 2000 4401 Great America Parkway Santa Clara, CA 95054...
Page 2: Restricted Rights Legend
Nortel Networks NA Inc. does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
Page 3 Software is provided will be free from defects in materials and workmanship under normal use for a period of 90 days from the date Software is first shipped to Licensee. Nortel Networks will replace defective media at no charge if it is returned to Nortel Networks during the warranty period along with proof of the date of shipment.
Page 4 Licensee will immediately destroy or return to Nortel Networks the Software, user manuals, and all copies. Nortel Networks is not liable to Licensee for damages in any form solely by reason of the termination of this license. 8. Export and Re-export. Licensee agrees not to export, directly or indirectly, the Software or related technical data or information without first obtaining any required export licenses or other governmental approvals.
Page 5: Table Of Contents
Preface Before You Begin ...xiii Text Conventions ...xiv Acronyms ... xv Hard-Copy Technical Manuals ...xix How to Get Help ... xx The Show Commands Accounting Show Commands ... 2 show accounting interfaces stats ... 2 show accounting interfaces summary ... 3 show accounting rules ...
Page 6 show atm vc ... 18 show atm vp ... 19 BGP Show Commands ... 20 show bgp damped-routes ... 20 show bgp debug ... 21 show bgp errors ... 21 show bgp peers ... 22 show bgp routes ... 23 show bgp stats ...
Page 7 show ethernet all ... 46 show ethernet auto-neg ... 46 show ethernet errors ... 47 show ethernet flow-control ... 49 show ethernet qos stats ... 49 show ethernet qos summary ... 50 show ethernet sample ... 51 show ethernet stats ... 51 show ethernet summary ...
Page 8 IGMP Show Commands ... 71 show igmp groups ... 71 show igmp interfaces state ... 72 show igmp interfaces timers ... 73 show igmp stats ... 73 show igmp summary ... 74 IP Show Commands ... 75 show ip adjacent-hosts ... 75 show ip alerts ...
Page 9 show ip stats fragments ... 94 show ip stats interface ... 94 show ip summary ... 95 show ip traffic ... 97 IS-IS Show Commands ... 100 show isis interfaces ... 100 show isis l2lspdb ... 100 show isis l2stats ... 101 show isis lspdetail ...
Page 10 show oc3 partition connector ... 124 show oc3 partition path ... 124 show oc3 partition virtual-container ... 125 show oc3 partition virtual-tributary ... 125 show oc3 state ... 125 show oc3 summary ... 126 PCAP Show Commands ... 127 show pcap config ... 127 show pcap state ...
Page 11 show sonet history ... 146 System Show Commands ... 147 show system information ... 147 show system memory ... 147 show system protocols ... 147 show system tasks ... 148 T1 Show Commands ... 149 show t1 bert-stats ... 149 show t1 ds1 ansi errors ...
Page 12 TCP Show Commands ... 190 show tcp connections ... 190 show tcp stats ... 190 Telnet Show Command ... 192 show telnet ... 192 TFTP Show Command ... 193 show tftp ... 193 Version Show Command ... 194 show version ... 194 308689-B Rev 00...
Page 13: Preface
Before using this guide, you must complete the following procedures. For a new Versalar 15000: • Install the Versalar 15000 and connect it to the network (see Installing and Maintaining the Versalar Switch Router 15000). • Develop a working knowledge of the BCC and Differentiated Services for the Versalar Switch Router 15000 and the Quick Reference for the Versalar Switch Router 15000).
Page 14: Text Conventions
Text Conventions This guide uses the following text conventions: angle brackets (< >) bold text braces ({}) brackets ([ ]) italic text Indicate that you choose the text to enter based on the description inside the brackets. Do not type the brackets when entering the command.
Page 15: Acronyms
screen text vertical line ( Acronyms This guide uses the following acronyms: BECN BERT BofL 308689-B Rev 00 Indicates system output, for example, prompts and system messages. Example: Set Trap Monitor Filters Separates choices for command keywords and arguments. Enter only one of the choices. Do not type the vertical line when entering the command.
Page 16 CSES CSNP DLCI DLCMI DVMRP ES-IS FEBE FECN FIFO HDB3 HDLC IBGP C-bit errored seconds committed information rate coded mark inversion cyclic redundancy check C-bit severely errored seconds complete sequence number packet controlled slip second Defense Data Network data link connection identifier data link control management interface degraded minutes direct memory access...
Page 17 ICMP IETF IGMP IS-IS LLC-SNAP LSDB MOSPF NBMA NSSA 308689-B Rev 00 Internet Control Message Protocol Internet Engineering Task Force Internet Forwarding Processor Internet Group Multicast Protocol Intermediate System to Intermediate System line coding violation line errored seconds Logical Link Control-Subnetwork Access Protocol Local Management Interface loss of frame loss of pointer...
Page 18 OSPF PLIM PROM PSES PSNP SEFS SNMP SSES xviii out of frame Open Shortest Path First peak cell rate path coding violation Public Data Network protocol data unit path errored seconds Protocol Independent Multicast Physical Layer Interface Module path signal label mismatches Point-to-Point Protocol programmable read-only memory path severely errored seconds...
Page 19: Hard-Copy Technical Manuals
TFTP Hard-Copy Technical Manuals You can print selected technical manuals and release notes free, directly from the Internet. Go to support.baynetworks.com/library/tpubs/. Find the product for which you need documentation. Then locate the specific category and model or version for your hardware or software product. Using Adobe Acrobat Reader, you can open the manuals and release notes, search for the sections you need, and print them on most standard printers.
Page 20: How To Get Help
The “Technical Manuals” section lists available printed documentation sets. How to Get Help If you purchased a service contract for your Nortel Networks product from a distributor or authorized reseller, contact the technical support staff for that distributor or reseller for assistance.
Page 21: The Show Commands
Example show ip stats datagrams ? bcc> show ip stats datagrams [<cct_name>] bcc> The following sections describe the commands for the Versalar 15000. show They are presented in alphabetical order by show command name. 308689-B Rev 00...
Page 22: Accounting Show Commands
Accounting Show Commands This section provides information on the accounting show commands and the command options you can enter. It also describes the information in the tables the router displays. show accounting interfaces stats show accounting interfaces stats statistics collected for configured interfaces and queues. This command allows for the following options: -queue <name>...
Page 23: Show Accounting Interfaces Summary
Note that if the interface is not working when you request statistics, the word down appears in the output to indicate that no statistics are available. Accounting Interface Statistics Name Service Queue Time Package (GMT) int1 pkg1 queue 4/04/00 @ 14:05 If the interface was not working during the current interval, but is now back up when you request statistics, the word partial appears.
Page 24: Show Accounting Rules
Queue Rule show accounting rules show accounting rules Versalar 15000. This command allows for the following option: <rule_name> The output includes the following information: Rule Name Direction Count Name of the queue for which to collect statistics. Name of the rule which defines the set of statistics to collect.
Page 25: Show Accounting Summary
show accounting summary show accounting summary service and the values of key attributes. The output includes the following information: State Status Log Level Circular Buffers Collect Duration (hrs.) Update Interval (min.) Flush on Retrieval Last Update (GMT) Last Flush (GMT) 308689-B Rev 00 command displays the state of the accounting Configured state of the accounting service.
Page 26 Rules Defined Queues Configured Snapshots in Memory Number of rules defined. Number of queues configured with accounting rules. Number of snapshots in memory. 308689-B Rev 00...
Page 27: Arp Show Command
ARP Show Command This section describes the ARP show command and the information in the tables the router displays. show arp show arp This table shows the mapping between the host address, its MAC address, and how the address was learned. The output includes the following information about each host listed: Address Hardware Addr...
Page 28: Atm Show Commands
ATM Show Commands This section provides information on the asynchronous transfer mode (ATM) show commands and the command options you can enter. It also describes the information in the tables the router displays. show atm interface show atm interface specified ATM interface. This command allows for the following option: <slot/connector>...
Page 29: Show Atm Line Errors
Setting for the ATM line interface: enabled or disabled. Current operational state: up, down, init, or notpresent. Virtual path connections (VPCs). The Versalar Switch Router 15000 does not support the configuration of individual VPCs. As a result, this value will always be 0.
Page 30: Show Atm Line Phy Errors
Transmit Oversized PDUs Transmit Packet Clips show atm line phy errors This command displays the ATM module physical interface errors table. You can specify any of the following filters (flags) with this command: -disabled -enabled -slot <name> The output includes the following physical interface error statistics: Slot/Module/Connector Circuit HEC Detected...
Page 31: Show Atm Line Sample
The output includes the following information: Slot/Module/Connector Circuit State Physical Medium Framing Mode Clock Source Scrambling show atm line sample This command displays the total number of frames transmitted and received for the specified circuit over the specified period of time, or for all circuits over 10 seconds.
Page 32: Show Atm Line State
Receive Octets Transmit Octets show atm line state show atm line state in this table contain the current configuration state of each ATM line driver. You can specify any of the following filters (flags) with this command: -disabled -enabled -slot <name> The output includes the following information: Slot/Module/Connector Circuit...
Page 33: Show Atm Line Stats
show atm line stats show atm line stats entries in this table contain real-time operational statistics for each ATM line driver. You can specify any of the following filters (flags) with this command: -disabled -enabled -slot <name> The output includes the following module I/O statistics: Slot/Module/Connector Circuit Receive Packets...
Page 34: Show Atm Pvc-Groups
show atm pvc-groups show atm pvc-groups router, or more specific information based on the filters you use. You can use the following filters with this command: -group <group> -service <service_name> -slot <slot> [/ <connector> ] -vci <vci> -vpi <vpi> -slot <slot> [/ <connector> ] The output includes the following information: Slot/Module/Connector PVC Group Name...
Page 35: Show Atm Services
show atm services show atm services subset of service record instances, along with the AAL data encapsulation type, state, VC type, and ATM address (a combination of network prefix and user part). This command allows for the following command filters (flags) and filter arguments: -slot <slot>...
Page 36: Show Atm Stats Line
show atm stats line show atm stats line line. This command allows for the following command filters (flags) and filter arguments: -disabled -enabled -slot <slot> [/ <connector> ] The output includes the following information: Slot/Conn Circuit Receive Packets Transmit Packets Receive Octets Transmit Octets command displays statistical information for each ATM...
Page 37: Show Atm Stats Vcs
show atm stats vcs show atm stats vcs table. This table contains statistical information for all ATM VCs on the router or specific information based on the filters you use. This command allows for the following command filters (flags) and filter arguments: -slot <slot>...
Page 38: Show Atm Traffic
show atm traffic show atm traffic information to and from all ATM networks connected to the routers. The output includes the following information: Input packets Output packets OAM cells received OAM cells sent show atm vc show atm vc information. This command allows for the following options: [-service] <service_name>...
Page 39: Show Atm Vp
Burst cells State show atm vp show atm vp interface or displays statistics for a specific VP. This command allows for the following option: <vpi> The output includes the following information: ATM slot/connector VPI VPI_identifier Name Type AAL/Encaps State 308689-B Rev 00 Maximum number of ATM cells the virtual circuit can transmit at peak rate.
Page 40: Bgp Show Commands
BGP Show Commands This section describes the Border Gateway Protocol (BGP) show commands, their command options, and the information in the tables the router displays. The BGP show commands display routing, configuration, interface, and statistical data about the BGP from the management information base (MIB). show bgp damped-routes show bgp damped-routes damped routes.
Page 41: Show Bgp Debug
show bgp debug show bgp debug the debug option. Debug allows packet information to be sent to the log. This command allows for the following command filter (flag) and filter arguments: -remote-address <value> <value> The output includes the following information: Local Address Remote Address Log Packet Types...
Page 42: Show Bgp Peers
Last Error Code Last Error Source show bgp peers show bgp peers command allows for the following command filter (flag) and filter arguments: -remote-address <value> <value> The output includes the following information: Local Address/Port Remote Address/Port Remote AS Peer Mode State BGP Ver Total Routes...
Page 43: Show Bgp Routes
show bgp routes show bgp routes allows for the following command filters and arguments: <ip_address> ip_address/prefix < The output includes the following information: Prefix/Length Peer Address Next Hop Address LocPref 308689-B Rev 00 command displays the BGP routing table. This command Displays BGP routes for the specified IP address.
Page 44: Show Bgp Stats
show bgp stats Displays BGP statistical information. This command allows for the following command filter (flag) and filter arguments: -remote-address <value> <value> The output includes the following information: Local Address Remote Address Messages Rx Messages Tx Updates Rx Updates Tx show bgp summary show bgp summary information.
Page 45: Show Bgp Timers
Indicates whether BGP is running as a soloist on the specified slot. Identifier for the blackhole support switch. Possible values here are: disabled (1), drop (2), or reject (3). If disabled , BGP does not submit a blackhole route to the IP routing table for an aggregate route advertised to a BGP peer.
Page 46 The output includes the following information: Local Address Remote Address Hold Cfg Act Keep Cfg Act Up/Down Time (HH:MM:SS) Last Update (HH:MM:SS) IP address of the local interface. IP address of the remote interface. Amount of time (in seconds) that either peer waits for a keepalive or update message before declaring the connection down.
Page 47: Buffers Show Command
Buffers Show Command This section describes the buffers show command and the information in the tables the router displays. show buffers show buffers on the router. Although buffers circulate rapidly through the system, a low free percentage does not necessarily indicate a buffer shortage; it may be a transient condition.
Page 48: Config Show Command
Config Show Command This section describes the config show command and the command options you can enter. It also describes the information in the tables the router displays. show config To display the configuration commands and data, enter the following command: show config [-all If you enter current context.
Page 49: Console Show Commands
Console Show Commands This section describes the console show commands and the information in the tables the router displays. show console config Enter the show console config environment information for the serial ports configured on your system or for a specific port.
Page 50 Modem Enable Lines/Screen More Enable Login Retries Login Timeout (min.) Slot Number Port Prompt Password Timeout (min.) Command Timeout (min.) History Depth # files to Autosave Volume for Autosave Configuration of modem control, as follows: • Disabled -- Port is directly connected to a device, such as a dummy terminal or a terminal server.
Page 51: Show Console Stats
show console stats Enter the show console stats port error statistics. The output includes the following information: Port Number Port Name Port State Total Logins User Login Errors Manager Login Errors Other Login Errors TTY Frame Errors TTY Overrun Errors TTY Parity Errors TTY FIFO Errors 308689-B Rev 00...
Page 52: Controller Show Commands
Controller Show Commands This section describes the controller show commands and the information in the tables the router displays. show controllers atm show controllers atm on a router. This command allows for the following options: <slot/connector> The output includes the following information: SECTION BIP (B1) LINE...
Page 53: Show Controllers T3
HCS errors Correctable HCS errors Uncorrectable HCS errors show controllers t3 show controllers t3 interfaces on the router and the data received and sent by the router. This command allows for the following arguments: slot/connector The output displays the following information: Slot/Conn Processor H/W Rev Processor Ser No...
Page 54 PSES SEFS CSES All T3 Time Intervals Slot/Conn Interval PSES SEFS CSES T3 Total (last 24 hours) PSES SEFS CSES Number of path errored seconds. Number of path severely errored seconds. Number of severely errored framing seconds. Number of unavailable seconds. Number of line errored seconds.
Page 55 Slot/Conn/Channel/Line Admin State Timeslots Alarm Framing Line Code Clock Source T1 Current Interval Time Elapsed T1 Total (last 24 hours) 308689-B Rev 00 Slot number, connector number, channel number, and line number of the T1 connection. Administrative state: up or down. Timeslots assigned to T1.
Page 56: Dns Show Commands
DNS Show Commands This section describes the DNS show commands and the command options you can enter. It also describes the information in the tables the router displays. show dns server Enter show dns server The output includes the following information: Server Address Port...
Page 57: Dvmrp Show Commands
DVMRP Show Commands This section describes how to use the BCC routing, configuration, interface, and statistical data about the Distance Vector Multicast Routing Protocol (DVMRP) from the management information base (MIB). show dvmrp cache show dvmrp cache each slot on the router. This command allows for the following options: -s <slot #>...
Page 58: Show Dvmrp Interfaces
show dvmrp interfaces show dvmrp interfaces DVMRP interfaces. This command allows for the following options: -disabled -enabled <ip_address> <ip_address_search_ pattern> The output includes the following information: Interface Circuit State Metric TTL Threshold Route Enabled Advertise Self command displays information about the configured Displays information about disabled DVMRP interfaces only.
Page 59: Show Dvmrp Neighbors
show dvmrp neighbors This command displays all DVMRP neighbor information or neighbor information for a specified circuit. show dvmrp neighbors -name <circuit_name> The output includes the following information: Circuit Local Tunnel IP Neighbor IP Neighbor Timer show dvmrp routes detail show dvmrp routes detail maintained on all DVMRP interfaces (both physical and tunnel).
Page 60: Show Dvmrp Routes Main
The output includes the following information: Source Network State Local IP Remote Tunnel Dominant Router Sub Router show dvmrp routes main show dvmrp routes main table. You can specify routes that match an IP address or routes with a source network number that matches a portion of an IP address (for example, 192.34.3.3 or 192.34.0.0/16).
Page 61: Show Dvmrp Stats Interfaces
Cost State show dvmrp stats interfaces show dvmrp stats interfaces DVMRP interfaces. You can specify any of the following options with this command: <interface_ip_address> -i <interface_ip_address> <interface_ip_address_ search_pattern> -c <circuit_name> The output includes the following information: Interface Circuit Fwd Cache Entries Prune Pkts In Prune Pkts Out Graft Pkts In...
Page 62: Show Dvmrp Stats Tunnels
show dvmrp stats tunnels show dvmrp stats tunnels DVMRP tunnels. You can specify any of the following options with this command: <local_interface_ip_ address> -local <local_interface_ ip_address> <remote_interface_ip_ address> -remote <remote_ interface_ip_address> The output includes the following information: Interface Interface Local Interface Remote Fwd Cache Entries Prune Pkts In...
Page 63: Show Dvmrp Summary
State Pruning Full Update Interval Trigger Update Interval Leaf Timeout Neighbor Timeout Neighbor Probe Interval Switch Timeout Route Expiration Timeout Unconfirmed Route Timeout Estimated Routes Actual Routes 308689-B Rev 00 command displays current configuration information State of DVMRP base module: Up, Down, Init (initializing), or Notpres (not present).
Page 64: Show Dvmrp Tunnels
show dvmrp tunnels show dvmrp tunnels information for all circuits, a specified circuit, enabled circuits, or disabled circuits. This command allows for the following options: -disabled -enabled <ip_address> or -local <ip_address_search_ pattern> -remote <ip_address> or <ip_address_search_ pattern> <ip_address> or <ip_address_search_ pattern>...
Page 65 Data Encapsulation Control Encapsulation 308689-B Rev 00 Mode that DVMRP uses to encapsulate a tunneled multicast datagram: • IP-in-IP -- DVMRP encapsulates the tunneled multicast datagram in an IP unicast datagram (ip-in-ip). • LSSR -- DVMRP loosely encapsulates multicast datagrams using the LSSR option. Encapsulation mode for IGMP control packets: •...
Page 66: Ethernet Show Commands
Ethernet Show Commands This section describes the Ethernet show commands and the command options you can enter. It also describes the information in the tables the router displays. show ethernet all show ethernet all a specific circuit or slot. show ethernet auto-neg show ethernet auto-neg Ethernet circuits that are configured with automatic line negotiation.
Page 67: Show Ethernet Errors
show ethernet errors show ethernet errors errors for all Ethernet circuits or for a specific circuit or slot. This command allows for the following command filter (flag) and filter argument: -slot <slot> The output includes the following information: Receive Errors Slot/Conn Checksum Errors Alignment Errors...
Page 68 Internal MAC Errors Deadlock Errors Excessive Collisions Late Collisions System Errors Slot/Conn Memory Errors Collision Errors Internal Errors Loss of Carrier Number of excessive deferrals. An excessive deferral indicates that during the previous transmission the deferral time was greater than 2.46 ms and the transmission was aborted.
Page 69: Show Ethernet Flow-Control
show ethernet flow-control Flow-control is a method used to control the transfer of data between two points on a data network. This avoids data loss when the receiving device buffer is full. show ethernet flow control feature on this router. This command allows for the following option: -slot <slot>...
Page 70: Show Ethernet Qos Summary
The output includes the following information: slot/conn Queue Tx Packets Tx Octets Dropped Packets show ethernet qos summary show ethernet qos summary information for each interface. This command allows for the following options: -slot <slot> -package-name <arg> The output includes the following information: slot/conn Service Package Queue Name...
Page 71: Show Ethernet Sample
show ethernet sample show ethernet sample interfaces over a period of 10 seconds. You can change the number of seconds over which you want to sample the data, and you can display sampled data for a specific circuit or slot only. This command allows for the following command filter (flag) and filter argument: -period <number_of_seconds>...
Page 72 The output includes the following information: Slot/Conn State Total Time Up/Down Speed (Mbps) Receive Errors Transmit Errors Transmit Deferred Number of Buffers/Rx Number of Buffers/Tx Slot/Conn Receive Bytes Receive Frames Recv Avg. Pkt Transmit Bytes Transmit Frames Slot location of the Ethernet module within the chassis and the connector number.
Page 73: Show Ethernet Summary
Trans. Avg Packet Multicast Receive show ethernet summary show ethernet summary Ethernet circuits or a specific circuit or slot. This command allows for the following command filter (flag) and filter argument <slot/conn> The output includes the following information: Slot/Conn Admin State HW Address Operational State 308689-B Rev 00...
Page 74 Total Time Up/Down Errors Speed (Mbps) If the line is not up (Operational State does not equal up), then three dashes (---) appear. If the line is up (Operational State equals up), then the value appears in the form: hhhmmmsss where hh is hours, mm is minutes, and ss is seconds.
Page 75: Frame Relay Show Commands
Frame Relay Show Commands This section describes the frame relay show commands and the command options you can enter. It also describes the information in the tables the router displays. show frame-relay services show frame-relay services frame relay services, including the number of VCs. This command allows for the following command filters and filter arguments: -service <name>...
Page 76: Show Frame-Relay Stats Dlcmi
show frame-relay stats dlcmi show frame-relay stats dlcmi statistics for frame relay DLCMIs. This command allows for the following command filter and filter argument: -interface <name> The output contains the following information: Interface Maximum Num VCs Current Num VCs Sequence Counter Received Sequence Passive Sequence Passive Received...
Page 77: Show Frame-Relay Summary
The output contains the following information: Interface Last Error -- Type Last Error -- Time Faults Outbound Drops Inbound Discards show frame-relay summary show frame-relay summary all frame relay interfaces. You can display the current operational status and interface type. The output includes the following information: Interface Circuit Management Type...
Page 78: Show Frame-Relay Vcs
• Active -- VC is usable. • Inactive -- VC is configured but not active. • Invalid -- VC is configured but the switch has not confirmed it. • Xoff -- VCs are XOFF’d. • Control -- Shows only control VCs.
Page 79 Interface on which the frame relay circuit resides. DLCI of the virtual circuit. State of the virtual circuit as follows: • Invalid -- Circuit is configured but the switch has not confirmed it. • Active -- Circuit is usable. •...
Page 80: Ftp Show Command
This section describes the FTP show command and the information in the table the router displays. show ftp show ftp the Nortel Networks File Transfer Protocol (FTP) service. For more information about the Nortel Networks implementation of FTP, see Configuring IP Services. The output includes the following information: Default Volume...
Page 81 Average In Kb/s In Errors Files Sent Avg Out Kb/s Out Errors 308689-B Rev 00 Average transfer rate in kilobytes per second for receiving data. Number of errors logged during in-bound transfer. Number of files successfully sent. Average transfer rate in kilobytes per second for sending data.
Page 82: Hardware Show Commands
Module serial number (in decimal format). Module type. Module revision (in decimal format). Module serial number (in decimal format). Type of backplane, Versalar Switch Router 15000, for example. Backplane revision (in decimal format). Backplane serial number (in decimal format). Status information for the fan tray module.
Page 83: Show Hardware Config-File
Power Supply Status Supply 1 Supply 2 show hardware config-file show hardware config-file configuration files. The output includes the following information: Slot File Name Load Date and Time show hardware image show hardware image loaded image source and name. The output includes the following information: Slot File Name Source...
Page 84: Show Hardware Memory
show hardware memory show hardware memory modules. The output includes the following information: Slot Local Memory Global Memory Total Memory show hardware prom show hardware prom Diag prom files. The output includes the following information: Boot PROM: Slot Revision Boot PROM date Diag PROM: Revision Diag PROM Date...
Page 85: Ifp Show Commands
IFP Show Commands This section describes the IFP show commands and the command options you can enter. It also describes the information in the tables the router displays. show ifp buffers show ifp buffers Forwarding Processor (IFP) buffers. This command allows for the following option: -slot <slot>...
Page 86: Show Ifp Input-Ports
Receive CRC Errors Bad Descriptor Dispatch Miss show ifp input-ports show ifp input-ports configuration of the IFP input ports. The output includes the following information: IFP Slot Primary CAP Secondary CAP Trunk Slot SSP (DPI) show ifp interrupts show ifp interrupts occurring on the IFP.
Page 87: Show Ifp Queues Trunk
TP CRC Interrupts Large Frame Interrupts show ifp queues trunk show ifp queues trunk outbound queues destined for the specified trunk slots. This command allows for the following option: -slot <slot> The output includes the following information: IFP Slot TP11 Hi-Depth/Clip Lo-Depth/Clip TP12 Hi-Depth/Clip Lo-Depth/Clip...
Page 88: Show Ifp Queues Multicast
AP4 Hi-Depth/Clip Lo-Depth/Clip AP5 Hi-Depth/Clip Lo-Depth/Clip show ifp queues multicast show ifp queues multicast outbound multicast queues. This command allows for the following option: -slot <slot> The output includes the following information: IFP Slot Multicast Hi-Depth/Clip Lo-Depth/Clip show ifp queues ssp show ifp queues ssp outbound SSP queues.
Page 89: Show Ifp Stats
show ifp stats show ifp stats that have been processed in non-forwarding code paths. This command allows for the following option: -slot <slot> The output includes the following information: IFP Slot SSP Deliver Hi/Lo SSP IP Deliver Hi/Lo SSP Deliver Lo Clip Blackhole Drops SSP Bypass Sent SSP Ucast/Bcast QoS Sent...
Page 90 The output includes the following information: IFP Slot State Active Streams Slot number of the IFP. Present state of the RSP forwarding processor. Possible values here are: down, nofwd, init or up. Bit mask (0-31) of active RSP instruction streams. Each bit set to a one indicates the stream is active.
Page 91: Igmp Show Commands
IGMP Show Commands This section provides information on the IGMP (Internet Group Management Protocol show commands and the command options you can enter. It also describes the information in the tables the router displays. show igmp groups show igmp groups registered per interface on the router.
Page 92: Show Igmp Interfaces State
show igmp interfaces state show igmp interfaces state interface currently in use. This command allows for the following options: <interface_ip_address> i <interface_ip_address> <interface_ip_address_ search_pattern> -c <circuit_name> -p <routing_protocol> The output includes the following information: Interface Circuit State Protocol Querier command displays information about the IGMP Displays IGMP interface information for the interface with the specified IP address only.
Page 93: Show Igmp Interfaces Timers
show igmp interfaces timers This command displays information about IGMP timers. This command allows for the following options: <interface_ip_address> i <interface_ip_address> <interface_ip_address_ search_pattern> -c <circuit_name> The output includes the following information: Interface Circuit Query Rate Querier Timeout Membership Timeout show igmp stats show igmp stats circuits.
Page 94: Show Igmp Summary
<interface_ip_address_ search_pattern> -c <circuit_name> The output includes the following information: Interface Circuit In Queries Out Queries Discards Groups Learned show igmp summary show igmp summary information. The output includes the following: State Estimated Groups Actual Groups Fwd-cache-limit Displays information for the interface at the IP addresses in the specified search criteria only.
Page 95: Ip Show Commands
IP Show Commands This section describes the IP show commands and the command options you can enter. It also describes the information in the tables the router displays. show ip adjacent-hosts show ip adjacent-hosts hosts. The table includes the following information: Host Address Encaps Valid ?
Page 96: Show Ip Arp
show ip arp show ip arp table. This table shows the mapping between the host IP address, its MAC address, and how the IP address was learned. This command allows for the following command filters (flags) and filter arguments: mac-address <mac> -interface <name>...
Page 97: Show Ip Disabled
show ip disabled show ip disabled interfaces. The output includes the following information: Circuit Cct # State IP Address Mask show ip enabled show ip enabled The output includes the following information: Circuit Cct # State IP Address Mask MAC Address show ip filter interface show ip filter interface configured on IP interfaces.
Page 98: Show Ip Icmp Client
The output includes the following information: Interface Filter State Status Prec In/Out Action Hits show ip icmp client show ip icmp client statistics about ICMP packets for all IP addresses or for a specific IP address. This command allows for the following option: <circuit_name>...
Page 99: Show Ip Icmp In
show ip icmp in show ip icmp in for all IP addresses or for a specific IP address. This command allows for the following option: <circuit_name> The output includes the following information: Circuit IP Address ICMP Received ICMP In Errors Destn.
Page 100: Show Ip Icmp Out
Redirect Messages In/Out Prohibit In/Out show ip icmp out show ip icmp out router generates on each IP address or on a specific IP address. This command allows for the following option: <circuit_name> The output includes the following information: Circuit IP Address ICMP Sent ICMP In Errors...
Page 101: Show Ip Interface
The output includes the following information: Circuit IP Address Echo Requests Echo Replies Timestamp Reqs Timestamp Repls Address Mask Requests Address Mask Replies show ip interface show ip interface configured on the router. This command allows for the following command filters (flags): -alerts -enabled...
Page 102: Show Ip Ospf
show ip ospf show ip ospf The output includes the following information: Routing state Routing ID Type of routes supported Number of SPF Number of areas in router Area border router AS boundary router NSSA border router Slot running primary Slot running backup Non-NSSA Areas Area ID...
Page 103: Show Ip Ospf Ase
Propagate type-7 default route LSA Type-7 default route path type show ip ospf ase show ip ospf ase external (ASE) advertisements. You can display information about all link state IDs on your router. The output includes the following information: Area ID Link State ID Originating Router Metric...
Page 104: Show Ip Ospf Interface
show ip ospf interface show ip ospf interface followed by a table of OSPF virtual interfaces. This command allows for the following option: <interface_name> The output includes the following information: Router ID OSPF Interfaces Internet Address Area Network Type Cost Transmit Delay State Priority...
Page 105: Show Ip Ospf Io
Retrans OSPF Virtual Interfaces Area ID Virtual Neighbor State show ip ospf io show ip ospf io that the router has sent and received. The output includes the following information: Interface Hellos Rx/Hellos Tx DBs Rx/DBs Tx LS Req Rx/LS Req Tx LS Upd Rx/LS Upd Tx LS Ack Rx/LS Upd Tx Drop...
Page 106 The output includes the following information: Area ID Router ID Link State ID LS Type Forward Address Displays the LSDB count. Displays the type of OSPF Link State Advertisement (LSA). Identifier of the area from which the LSA was received. Identifier for the originating router in the autonomous system.
Page 107: Show Ip Ospf Neighbors
show ip ospf neighbors show ip ospf neighbors The output includes the following information: IP interface Router ID Neighbor IP Address State Type 308689-B Rev 00 command displays a table of all OSPF’s neighbors. IP address of the interface for the neighbor (OSPF dynamic and configured neighbors only).
Page 108: Show Ip Ospf Nssa-Range
show ip ospf nssa-range show ip ospf nssa-range not-so-stubby area (NSSA) type-7 address range. The output includes the following information: Network Address Network Mask Action External Route Tag show ip rip alerts show ip rip alerts have RIP configured but the state of RIP is down. The output includes the following information: IP Interface Cct #...
Page 109: Show Ip Rip Auth
show ip rip auth show ip rip auth which RIP performs authentication. You can configure authentication when you set the RIP version to RIP2. The output includes the following information: IP Interface Cct # Type Password show ip rip disabled show ip rip disabled configured but disabled.
Page 110: Show Ip Rip Enabled
show ip rip enabled show ip rip enabled enabled on them. The output includes the following information: IP Interface Cct # State RIP Sup/Lis Def. Rt. Sup/Lis Poison Reverse RIP Mode Trig. Updates show ip rip summary show ip rip summary configured.
Page 111: Show Ip Rip Timers
RIP Mode Trig. Updates show ip rip timers show ip rip timers control periodic RIP updates (broadcast), when RIP declares a route invalid (timeout), and the length of time a route is advertised with an infinite metric (holddown). The output includes the following information: IP Interface Cct # Broadcast Timer...
Page 112: Show Ip Static
The table includes the following information: Destination/Mask Proto Cost NextHopAddr / AS show ip static show ip static router. The output includes the following information: IP Destination Network Mask Cost Next Hop Displays the entire routing table; routes marked with an asterisk (*) are routes in the normal routing table.
Page 113: Show Ip Stats Datagrams
Valid Enabled show ip stats datagrams show ip stats datagrams datagrams that IP has processed for all IP addresses or for a specific IP address or circuit. This command allows for the following option: <circuit_name> The output includes the following information: Circuit IP Address Header Errors...
Page 114: Show Ip Stats Fragments
show ip stats fragments show ip stats fragments fragmented IP packets for all IP addresses or for a specific IP address or circuit. This command allows for the following option: <circuit_name> The output includes the following information: Circuit IP Address Frag Receives Success Reassemblies Failed Reassemblies...
Page 115: Show Ip Summary
The output includes the following information: Circuit IP Address In Receives Out Requests Forwards In Discards Out Discards show ip summary show ip summary forwarding mode or in host mode only. The base record controls IP for the entire system. The output includes the following information: Configured State Current State Number of Routes...
Page 116 All Subnets Directed Broadcast ARP % Buffer Limit ICMP Error Limit ECMP Method Maximum RIP Paths Maximum OSPF Paths Maximum ISIS Paths Administratively controls the use of the zero and all-ones subnets for configured IP interfaces. Administratively controls whether or not received packets with a destination address corresponding to an interface directed broadcast address are forwarded.
Page 117: Show Ip Traffic
show ip traffic show ip traffic pass through the IP network. The output includes the following information: IP statistics Rcvd: Frags: Mcast: Sent: Drop: 308689-B Rev 00 command displays information on the data and packets that Statistics on the datagrams received over a specified time: •...
Page 118 ICMP statistics: Rcvd: Sent: Statistics on ICMP packets over a specified time: • received -- number of packets received. • errors -- number of errors. • destn unreachable -- number of packets labeled with an unreachable destination. • param problem -- number of packets with parameter problems.
Page 119 UDP statistics: Rcvd: Sent: TCP statistics: Rcvd: Sent: EGP statistics: Rcvd: Sent: OSPF statistics Rcvd: Sent: IGMP statistics: Rcvd: Sent: 308689-B Rev 00 Statistics on UDP datagrams over a specified time: • total packets -- total number of datagrams received. •...
Page 120: Is-Is Show Commands
IS-IS Show Commands This section describes the IS-IS show commands and the command options you can enter. It also describes the information in the tables the router displays. show isis interfaces show isis interfaces IS-IS interfaces. This command allows for the following command filter (flag) and filter argument: [-ip-address] <ip-address>...
Page 121: Show Isis L2Stats
The output includes the following information: LSP ID Lifetime Sequence # Flags (P/ATT/OL/IS) Checksum show isis l2stats show isis l2 stats information. This command allows for the following command filter (flag) and filter argument: [-ip-address] <value> The output includes the following information: IP Address Hellos Tx/Hellos Rx LSPs Tx/LSPs Rx...
Page 122: Show Isis Neighbors
show isis lspdetail show isis lspdetail in the database. This command allows for the following command filter (flags) and filter argument: -l <isp-id> The output includes the following information: LSP ID Lifetime Sequence # Flags (P/ATT/OL/IS) Checksum show isis neighbors show isis neighbors neighbors on each interface.
Page 123 show isis summary show isis summary interface. The output includes the following information: Router ID Admin State Oper State Type L1 LSP Count L1 SPF Count L1 Corrupted LSP Count L1 LSP DB Overloads L1 Routes Count L2 LSP Count L2 SPF Count L2 Corrupted LSP Count L2 LSP DB Overloads...
Page 124: Logical-Line Show Commands
Logical-Line Show Commands This section describes the logical-line show commands and the command options you can enter. It also describes the information in the tables the router displays. show logical-line bert-stats show logical-line bert-stats (BERT) statistics collected for a specified circuit. This command allows for the following option: -slot <slot>...
Page 125: Show Logical-Line Errors
show logical-line errors show logical-line errors errors for all logical-line circuits or for a specific circuit or slot. This command allows for the following options: -slot <slot> -name <name> <value> The output includes the following information: Logical line over Mct3 errors Name Slot/Conn/Chan/Index Tx Underflow...
Page 126: Show Logical-Line Qos Stats
Logical line over Mcoc3 errors Name Slot/Conn/Chan/Index Tx Underflow Rx Overflow Rx Short Rx CRC Rx Non Octet Rx Long Rx Abort show logical-line qos stats show logical-line qos stats collected for a specified Quality of Service (QoS) interface or queue. This command allows for the following options: -slot <slot>...
Page 127 The output includes the following information: Logical line over Mct3 qos stats Name Slot/Conn/Chan/Index Queue RxBelowCIR Packets/Octets/Tx Packets RxAboveCIR Packets/Octets/Tx Drops RxAboveBR Packets/Octets/Tx Octets Logical line over Mcoc3 qos stats Name Slot/Conn/Chan/Index Queue RxBelowCIR Packets/Octets/Tx Packets RxAboveCIR Packets/Octets/Tx Drops RxAboveBR Packets/Octets/Tx Octets 308689-B Rev 00 User-defined name for the logical line.
Page 128: Show Logical-Line Qos Summary
show logical-line qos summary show logical-line qos summary information for all logical-line QoS interfaces or queues, or for a specific interface or queue. This command allows for the following options: -slot <slot> -package -name <name> -name <name> <value> The output includes the following information: Logical line over Mct3 qos summary Name Slot/Conn/Chan/Index...
Page 129: Show Logical-Line Sample Mcoc3
Queue/State Rx Commit/Tx Weight Rx Burst show logical-line sample mcoc3 show logical-line sample mcoc3 statistics collected for a specific logical-line interface. The output includes the following information: Name Slot/Conn/Chan/Index Bits/sec Received/Transmitted Frames/sec Received/Transmitted Drops/sec Received/Transmitted 308689-B Rev 00 Queue for which data was collected and the current state of this queue.
Page 130: Show Logical-Line Sample Mct3
show logical-line sample mct3 show logical-line sample mct3 statistics collected for a specific logical-line interface. The output includes the following information: Name Slot/Conn/Chan/Index Bits/sec Received/Transmitted Frames/sec Received/Transmitted Drops/sec Received/Transmit Number of packets per second dropped prior to command displays all packet and octet User-defined name for this logical line.
Page 131: Show Logical-Line Stats
show logical-line stats show logical-line stats collected for all logical-line interfaces or slots, or for a specific interface. This command allows for the following options: -slot <slot> -name <name> <value> The output includes the following information: Logical line over Mct3 stats Name Slot/Conn/Chan/Index Octets Received/Transmitted...
Page 132: Show Logical-Line Summary
show logical-line summary show logical-line summary information collected for a specified interface or slot. This command allows for the following options: -slot <slot> -name <name> <value> The output includes the following information: Logical line over Mct3 summary Name Slot/Conn/Chan/Index Admin/Oper State QoS Package WAN Protocol Rate Adaption...
Page 133: Show Logical-Line Timeslots
Logical line over Mcoc3 summary Name Slot/Conn/Chan/Index Admin/Oper State QoS Package WAN Protocol Rate Adaption show logical-line timeslots show logical-line timeslots logical-line circuits or for a specific circuit or slot configured as a logical line. This command allows for the following options: -slot { <slot>...
Page 134: Show Logical-Line Vc Qos Stats
The output includes the following information: Logical line over Mct3 timeslots Name Slot/Conn/Chan/Index Timeslots Logical line over Mcoc3 timeslots Name Slot/Conn/Chan/Index Timeslots show logical-line vc qos stats show logical-line vc qos stats statistics collected for a specified Quality of Service (QoS) interface or queue configured on a frame relay virtual circuit (VC).
Page 135 The output includes the following information: Logical line over Mct3 vc qos stats Name Slot/Conn/Chan/Index Queue/Dlci RxBelowCIR Packets/Octets/Tx Packets RxAboveCIR Packets/Octets/Tx Drops RxAboveBR Packets/Octets/Tx Octets Logical line over Mcoc3 vc qos stats Name Slot/Conn/Chan/Index Queue/Dlci RxBelowCIR Packets/Octets/Tx Packets RxAboveCIR Packets/Octets/Tx Drops RxAboveBR Packets/Octets/Tx Octets 308689-B Rev 00...
Page 136: Show Logical-Line Vc Stats
show logical-line vc stats show logical-line vc stats collected for a specified frame relay virtual circuit (VC). Only IP packets are included. This command allows for the following options: -slot <slot_number> -name <circuit_name> <circuit_name> The output includes the following information: Logical line over Mct3 vc stats Name Slot/Conn/Chan/Index...
Page 137 Logical line over Mcoc3 vc stats Name Slot/Conn/Chan/Index Dlci RxBelowCIR Packets/Octets/Tx Packets RxAboveCIR Packets/Octets/Tx Drops RxAboveBR Packets/Octets/Tx Octets 308689-B Rev 00 User-defined name for the logical line. Identifies the slot, OC3 connector, DS3 channel, DS1 channel, and the index for this line instance. The index ranges from 1 to 24 (for T1) and 1 to 31 (for E1).
Page 138: Modctl Show Command
Modctl Show Command This section provides information on the modctl show command and the information in the table the router displays. show modctl show modctl the MCD, and which slots are active. The output includes the following information: Primary SSP State Active Slots command displays which SSP is the primary one, the state of...
Page 139: Multicast Show Commands
Multicast Show Commands This section provides information on the multicast show commands and the command options you can enter. It also describes the information in the tables the router displays. show multicast stats control-packets show multicast stats control-packets information about control-packets for multicast. This command allows for the following options: <interface_ip_address>...
Page 140: Show Multicast Stats Data-Packets
show multicast stats data-packets show multicast stats data-packets information about data-packets for multicast. This command allows for the following options: <interface_ip_address> i <interface_ip_address> <interface_ip_address_ search_pattern> - c <circuit_name> The output includes the following information: Interface Circuit Data Packets Fast Path In Data Packets Fast Path Out Data Packets Slow Path In Data Packets Slow Path Out...
Page 141: Show Multicast Stats Source-Group
show multicast stats source-group show multicast stats source-group information about the traffic for the multicast source group. The output includes the following information: Group Source/Prefix Code pkt# fast pkt# idle sec Code 308689-B Rev 00 command displays statistical The IP address for the group. The IP address of the source of the data packet and its associated network prefix.
Page 142: Ntp Show Commands
NTP Show Commands This section describes the NTP show commands and the command options you can enter. It also describes the information in the tables the router displays. show ntp access Displays information about the Network Time Protocol (NTP) servers preferred (accepted) or restricted (rejected) by the local NTP client.
Page 143: Show Ntp Peers
show ntp peers Displays configuration and status information about NTP servers known to the NTP client on the router. The output includes the following information: IP Address Peer Mode State Ref. ID Preferred show ntp stats Displays information about the number of: •...
Page 144: Oc3 Show Commands
OC3 Show Commands This section provides information on the OC3 show commands and the command options you can enter. It also describes the information in the tables the router displays. show oc3 partition connector show oc3 partition connector for all OC3 connectors in the box. This command allows for the following option: <arg 1>...
Page 145: Show Oc3 Partition Virtual-Container
The output includes the following information: Slot Conn Path Configured show oc3 partition virtual-container show oc3 partition virtual-container release. show oc3 partition virtual-tributary show oc3 partition virtual-tributary release. show oc3 state show oc3 state OC3. You can specify any of the following filters (flags) with this command: -slot <arg>...
Page 146: Show Oc3 Summary
show oc3 summary show oc3 summary can specify any of the following filters (flags) with this command: -slot <arg> <arg 1> The output includes the following information: Slot/Conn Admin State Oper State Alarms Type Line Coding Line Type command displays summary information for OC3. You Displays information for the specified slot number.
Page 147: Pcap Show Commands
PCAP Show Commands This section describes the PCAP show commands and describes the information in the tables the router displays. show pcap config show pcap config configuration. The output of the command includes the following information Circuit Channel Buf Size (KB) Pkt Size (Bytes) show pcap state show pcap state...
Page 148 Capture Filename PktDump ID Number File name used to retrieve the capture buffer. The captured file name is listed as part of the PCAP summary data. The file name is formatted as follows: PCAP <ssnn> ss is the slot number. nn is a number from 00 to 99.
Page 149: Ppp Show Commands
PPP Show Commands This section describes the PPP show commands and the command options you can enter. It also describes the information in the tables the router displays. show ppp alerts show ppp alerts but whose state is not opened. This command allows for the following options: -name <value>...
Page 150: Show Ppp Bad-Packets
State show ppp bad-packets show ppp bad-packets received over each circuit and the first 16 bytes of the last bad packet. If the number of bad packets is greater than zero, then the PPP circuit is receiving misformed packets or packets meant for other protocols. The hexadecimal display of the last bad packet will show the kind of packet being received.
Page 151: Show Ppp Disabled
This command allows for the following option: -name <value> The output includes the following information: Name # Bad Packets Last Bad Packet show ppp disabled show ppp disabled Protocols (NCPs) disabled on each circuit. This command allows for the following options: -name <value>...
Page 152: Show Ppp Interfaces
The output includes the following information: Name Line Number Line State Protocol State show ppp interfaces show ppp interfaces interface configured on each circuit. This command allows for the following options: -name <value> -slot <value> <value> The output contains the following information: Name Slot/Conn/Channel Driver State...
Page 153: Show Ppp Line Config
The output includes the following information: Name State Local Config Local Address Remote Address show ppp line config show ppp line config PPP line parameter values for the specified interface. This command allows for the following options: -name <value> -slot <value> The output includes the following information: Name Slot/Conn/Channel...
Page 154: Show Ppp Line Params
Max Term Req Max Conf Fail show ppp line params show ppp line params parameters configured for the specified interface. This command allows for the following options: -name <value> -slot <value> The output includes the following information: Name Slot/Conn/Channel LCP State Magic Number Maximum number of unacknowledged terminate-request packets that the router transmits before assuming that...
Page 155: Processes Show Commands
Processes Show Commands This section describes the processes show commands and the command options you can enter. It also describes the information in the tables the router displays. show processes buffers detail show proccesses buffers detail percentage of buffers used by all processes on the router. This command allows for the following option: <entity_name>...
Page 156: Show Processes [ Cpu ]
show processes show processes seconds and the percentage of total CPU time used by all processes on the router. It displays CPU statistics totals and details about the CPU usage for all processes. Note: For information about how to obtain a list of available processes, see the show processes list The output includes the following information: Slot...
Page 157: Show Processes Memory
show processes memory show proccesses memory percentage of memory used by all processes on the router. The summary portion of the output displays memory usage totals. The detail portion of the output displays details about the amount of memory used by each process running on the router.
Page 158: Qos Show Commands
QoS Show Commands This section describes the QoS show commands and the command options you can enter. It also describes the information in the tables the router displays. show qos service-package queues show qos service-package queues information about each service package and its associated queues. This command allows for the following options: -rule <name>...
Page 159: Show Qos Service-Package Summary
show qos service-package summary show qos service-package summary information about the use of each service package on the router. This command allows for the following options: -package-name <name> <value> The output includes the following information: Service Package Scheduling Method Lines Used by # of Queues 308689-B Rev 00 command displays summary...
Page 160: Snmp Show Commands
Versalar Switch Router 15000. An SNMP community is a logical relationship between the SNMP agent on the Versalar Switch Router 15000 and one or more SNMP managers. The output includes information on the managers belonging to each community known to the router.
Page 161: Show Snmp Stats
Trap Type Community Name show snmp stats show snmp stats (PDUs) received and forwarded by SNMP. The output includes the following information: Authentication Type Received PDUs Transmitted PDUs MIB Objects Retrieved MIB Objects Set Get Request PDUs Accepted and Processed Get Next Request PDUs Accepted and Processed Get Response PDUs...
Page 162: Show Snmp Trap-Entity
Error Generated PDUs with readOnly Error Generated PDUS with genErr Error show snmp trap-entity show snmp trap-entity on the Versalar Switch Router 15000. The output includes the following information: Entity Name Entity Number Slot Number State Fault Message Total number of ANS.1 parsing errors during decoding.
Page 163: Show Snmp Trap-Event
• Off -- The Versalar Switch Router 15000 does not generate this trap whenever a fault event occurs for this entity and slot number. Attribute that controls the entity’s info messages: •...
Page 164: Sonet Show Commands
SONET Show Commands This section describes the SONET show commands and the command options you can enter. It also describes the information in the tables the router displays. show sonet current show sonet current The output includes the following information: SONET Entries Slot/Conn/Path Type...
Page 165 SESs UASs Status FarEndLine Slot/Conn Interval SESs UASs Path Layer Slot/Conn/Path Interval SESs UASs Width Status FarEndPath Slot/Conn/Path Interval SESs 308689-B Rev 00 Number of errored seconds (ESs) in the current interval. Number of severely errored seconds (SESs) in the current interval.
Page 166: Show Sonet Errors
UASs show sonet errors show sonet errors The output includes the following information: Section Slot/Module/Connector BIPs LOSs LOFs Line Slot/Connector BIPs FEBEs AISs RDIs Path Slot/Conn/Path BIPs FEBEs LOPs AISs RDIs PLMs show sonet history show sonet history To view the output of this command, see the -144.
Page 167: System Show Commands
System Show Commands This section describes the system show commands and the command options you can enter. It also describes the information in the tables the router displays. show system information show system information (system name, contact, node location, image data, MIB version, and total uptime since last cold boot).
Page 168: Show System Tasks
show system tasks show system tasks on all slots. This number is highly volatile and a large In-Queue value does not necessarily indicate a problem.The output includes the following information: Slot Total In_Queue % In Queue command displays the number of tasks scheduled to run Slot number.
Page 169: T1 Show Commands
T1 Show Commands This section describes the T1 show commands and the command options you can enter. It also describes the information in the tables the router displays. show t1 bert-stats show t1 bert-stats DS1. This command allows for the following options: -slot <name>...
Page 170: Show T1 Ds1 Ansi Errors
show t1 ds1 ansi errors show t1 ds1 ansi errors MCOC3 channels, or for a specific slot. This command allows for the following options: -slot <slot> -slot <slot/conn> -slot <slot/conn/chan> <value> value is any of the following: <slot> <slot/conn> <slot/conn/chan> The output includes the following information: T1 over Mct3 ansi errors Slot/Conn/Channel...
Page 171: Show T1 Ds1 Ansi Prm
show t1 ds1 ansi prm show t1 ds1 ansi prm MCT3 and MCOC3 channels, or for a specific slot. This command allows for the following options: -slot <value> <value> value is any of the following: <slot> <slot/conn> <slot/conn/chan> The output includes the following information: T1 over Mct3 ansi prm Slot/Conn/Channel PRMR0...
Page 172: Show T1 Ds1 Interval Current
T1 over Mcoc3 ansi prm Slot/Conn/Channel PRMR0 PRMR1 PRMR2 PRMR3 PRMES PRMSES PRME show t1 ds1 interval current show t1 ds1 interval current interval information for all MCT3 and MCOC3 channels, or for a specific slot. This command allows for the following options: -slot <value>...
Page 173 The output includes the following information: T1 over Mct3: Local: Slot/Conn/Channel Time Elapsed SEFS T1 over Mcoc3: Local: Slot/Conn/Channel Time Elapsed SEFS 308689-B Rev 00 Identifier for the slot, DS3 connector, and T1 channel. Number of hours:minutes:seconds (HH:MM:SS) that have elapsed since the beginning of the current error measurement period.
Page 174: Show T1 Ds1 Interval History
show t1 ds1 interval history show t1 ds1 interval history MCT3 and MCOC3 channels, or for a specific slot. This command allows for the following options: -slot <value> <value> value is any of the following: <slot> <slot/conn> <slot/conn/chan> The output includes the following information: T1 over Mct3: Local: Slot/Conn/Channel Interval...
Page 175 SEFS T1 over Mcoc3: Local: Slot/Conn/Channel Interval SEFS 308689-B Rev 00 Number of severely errored framing seconds (SEFSs) in the specified interval. Number of unavailable seconds (UASs) in the specified interval. Number of controlled slip seconds (CSSs) in the specified interval.
Page 176: Show T1 Ds1 State
show t1 ds1 state show t1 ds1 state MCOC3 channel circuits or for a specific slot. This command allows for the following options: -with-alarms -slot <value> <value> value is any of the following: <slot> <slot/conn> <slot/conn/chan> The output includes the following information: T1 over Mct3 state Slot/Conn/Channel Admin State...
Page 177: Show T1 Ds1 Summary
show t1 ds1 summary show t1 ds1 summary MCT3 and MCOC3 channels, or for a specific slot. This command allows for the following options: -slot <value> <value> value is any of the following: <slot> <slot/conn> <slot/conn/chan> The output includes the following information: T1 over Mct3 summary Mct3 Channel Administrative State...
Page 178 Fdl Type Fdl Prm Cr Send/Accept Fdl Loop Retention Accept Loopbacks Loopback State Loopback Action Code Sent T1 over Mcoc3 summary Slot/Conn/Channel Administrative State Operational State Alarms Pri/Sec Clock Actual Clock Framing Attribute used to configure the FDL type. The ANSI403 configures the port to use the FDL exchange described in the ANSI T1 403 specification.
Page 179 Setup Alarm Threshold Clear Alarm Threshold Fdl Address Fdl Type Fdl Prm Cr Send/Accept Fdl Loop Retention Accept Loopbacks Loopback State Loopback Action Code Sent 308689-B Rev 00 Minimum amount of time required before entering (or exiting) an alarm state due to changes on the DS1. One of two Facility Data Link (FDL) target address modes.
Page 180: Show T1 Errors
show t1 errors show t1 errors circuits or for a specific circuit. This command allows for the following options: -slot <name> -name <name> <value> The output includes the following information: T1 over Mct3 errors Name Slot/Conn/Channel Tx Underrun Rx Overrun Rx Short Rx CRC Rx Non Octet...
Page 181: Show T1 Qos Stats
Rx Short Rx CRC Rx Non Octet Rx Long Rx Abort show t1 qos stats show t1 qos stats for all MCT1 Quality of Service (QoS) circuits or for a specific circuit. This command allows for the following options: -slot <name> -name <name>...
Page 182: Show T1 Qos Summary
T1 over Mcoc3 qos stats Interface Queue RxBelowCIR Packets/Octets RxAboveCIR Packets/Octets RxAboveBR Packets/Octets Tx Packets/Octets Dropped Packets show t1 qos summary show t1 qos summary all MCT1 QoS circuits, or for a specific circuit. This command allows for the following options: -slot <name>...
Page 183 Queue Status Queue Weight CIR/BR (kbits/sec) T1 over Mcoc3 qos summary Interface Service Package Queue Name Queue Status Queue Weight CIR/BR (kbits/sec) Note that the Queue Status field does not reflect the actual status of a queue in use on the line. In the following examples, the queue is up in the first sample qos summary show t1 qos summary T1-1/3/28 T1 Qos Summary...
Page 184: Show T1 Sample
T1-1/3/28 T1-1/3/28 show t1 qos summary T1-1/3/28 T1 Qos Summary ------------------------------------------------------ Interface ----- T1-1/3/28 T1-1/3/28 T1-1/3/28 T1-1/3/28 To ensure that the queue is indeed up on a particular line, you need to enter the show t1 summary show t1 sample show t1 sample stats command, but displays only the data captured in a specified time interval.
Page 185: Show T1 Stats
The output includes the following information: T1 over Mct3 sample Name Slot/Conn/Channel Bits/sec Received/Transmitted Number of bits per second transmitted and received Frames/sec Received/Transmitted Drops/sec Received/Transmitted T1 over Mcoc3 sample Name Slot/Conn/Channel Bits/sec Received/Transmitted Number of bits per second transmitted and received Frames/sec Received/Transmitted Drops/sec...
Page 186: Show T1 Summary
The output includes the following information: T1 over Mct3 stats Name Slot/Conn/Channel Octets Received/Transmitted Frames Received/Transmitted Number of packets transmitted and received without Drops Received/Transmitted T1 over Mcoc3 stats Name Slot/Conn/Channel Octets Received/Transmitted Frames Received/Transmitted Number of packets transmitted and received without Drops Received/Transmitted show t1 summary show t1 summary...
Page 187 Admin/Oper State QoS Package WAN Protocol Rate Adaption T1 over Mcoc3 summary Name Slot/Conn/Channel Admin/Oper State QoS Package WAN Protocol Rate Adaption 308689-B Rev 00 Admin state is the configured state, either up or down. Oper state is the operational state, either alarm or up. QoS service package used by this circuit.
Page 188 The line is in state quemisCfg because there is a conflicting class and the queue is improperly configured. In such cases, the Versalar 15000 has run out of available queues. show t1 summary T1-1/3/28...
Page 189: Show T1 Vc Qos Stats
show t1 vc qos stats show t1 vc qos stats packets and bytes transmitted and received over the frame relay DLCI VC (virtual circuit) for queues configured through a service package. You can specify any of the following filters (flags) with this command: -slot <arg>...
Page 190: Show T1 Vc Stats
Tx Packets/Octets Dropped Packets show t1 vc stats show t1 vc stats packets and bytes transmitted and received over the frame relay DLCI VC (virtual circuit). This command allows for the following options: -slot <arg> -name <arg> <arg 1> The output includes the following information: T1 over Mct3 vc stats Interface/DLCI Circuit...
Page 191 RxAboveCIR Packets/Octets RxAboveBR Packets/Octets Tx Packets/Octets Dropped Packets 308689-B Rev 00 Number of packets/octets received that exceeded the CIR, but were within the allocated burst rate (BR). Number of packets/octets received that exceeded the allocated BR. Number of packets/octets transmitted. Number of packets that should have been transmitted, but that were dropped due to lack of buffering resources.
Page 192: T3 Show Commands
T3 Show Commands This section provides information on the T3 show commands and the command options you can enter. It also describes the information in the tables the router displays. show t3 ds3 interval current show t3 ds3 interval current for all MCT3 and MCOC3 connectors or for a specific slot.
Page 193 SSES PSES T3 over Mct3: FarEnd: Slot/Conn Time Elapsed CSES T3 over Mcoc3: Local: Slot/Conn/Channel Time Elapsed CSES SSES 308689-B Rev 00 Number of section severely errored seconds (SSESs) in the current interval. Number of path errored seconds (PESs) in the current interval.
Page 194: Show T3 Ds3 Interval History
PSES T3 over Mcoc3: FarEnd: Slot/Conn/Channel Time Elapsed CSES show t3 ds3 interval history show t3 ds3 interval history for all MCT3 and MCOC3 connectors or for a specific slot. This command allows for the following options: -slot <arg> <arg 1> The output includes the following information: T3 over Mct3: Local: Slot/Conn...
Page 195 CSES SSES PSES T3 over Mct3: FarEnd: Slot/Conn Time Elapsed CSES T3 over Mcoc3: Local: Slot/Conn/Channel Time Elapsed CSES 308689-B Rev 00 Number of c-bit severely errored seconds (CSESs) in the current interval. Number of c-bit coding violations (CCVs) in the current interval.
Page 196 SSES PSES T3 over Mcoc3: FarEnd: Slot/Conn/Channel Time Elapsed CSES Number of c-bit coding violations (CCVs) in the current interval. Number of unavailable seconds (UASs) in the current interval. Number of line coding violations (LCVs) in the current interval. Number of path coding violations (PCVs) in the current interval.
Page 197: Show T3 Ds3 State
show t3 ds3 state show t3 ds3 state MCOC3 connectors or for a specific slot. This command allows for the following options: -slot <arg> <arg 1> The output includes the following information: T3 over Mct3 Ds3 state Slot/Conn Administrative State Operational State Alarms T3 over Mcoc3 Ds3 state...
Page 198: Show T3 Ds3 Summary
show t3 ds3 summary show t3 ds3 summary and MCOC3 connectors or for a specific slot. This command allows for the following options: -slot <arg> <arg 1> The output includes the following information: T3 over Mct3 Ds3 summary Slot/Conn Administrative State Operational State Alarms Linecoding...
Page 199 Setup Alarm Threshold Clear Alarm Threshold Code Sent Cable Length Payload Type T3 over Mcoc3 Ds3 summary Slot/Conn/Channel Administrative State Operational State Alarms Linecoding Framing Actual Framing Pri/Sec Clock Actual Clock 308689-B Rev 00 Displays largest frame size that can be received by the MCT3 channel.
Page 200: Show T3 Errors
Loopback Config Setup Alarm Threshold Clear Alarm Threshold Code Sent Cable Length Payload Type show t3 errors show t3 errors circuits or for a specified T3 circuit. This command allows for the following options: -slot <arg> -name <arg> <arg 1> Displays loopback configuration of the DS1 interface.
Page 201 The output includes the following information: T3 over Mct3 errors Name Slot/Conn Tx Underflow Rx Overflow Rx Short Rx CRC Rx Non Octet Rx Long Rx Abort T3 over Mcoc3 errors Name Slot/Conn/Channel Tx Underflow Rx Overflow Rx Short Rx CRC Rx Non Octet Rx Long Rx Abort...
Page 202: Show T3 Qos Stats
show t3 qos stats show t3 qos stats for all MCT3 Quality of Service (QoS) circuits or for a specific T3 circuit. This command allows for the following options: -slot <arg> -name <arg> <arg 1> The output includes the following information: T3 over Mct3 qos stats Interface Queue...
Page 203: Show T3 Qos Summary
show t3 qos summary show t3 qos summary all MCT3 QoS circuits, or for a specific T3 circuit. This command allows for the following options: -slot <arg> -package-name <arg> -name <arg> <arg 1> The output includes the following information: T3 over Mct3 qos summary Interface Service Package Queue Name...
Page 204: Show T3 Sample
Queue Status Queue Weight CIR/BR (kbits/sec) show t3 sample show t3 sample command, but only displays the data captured in a specified time interval. stats This command allows for the following options: -slot <arg> -name <arg> -period <arg> <arg 1> The output includes the following information: T3 over Mct3 sample Name...
Page 205: Show T3 Stats
T3 over Mcoc3 sample Name Slot/Conn/Channel Bits/sec Received/Transmitted Number of bits per second transmitted and received Frames/sec Received/Transmitted Drops/sec Receive/Transmit show t3 stats show t3 stats for all MCT3 circuits or for a specific T3 circuit. You can specify any of the following filters (flags) with this command: -slot <arg>...
Page 206: Show T3 Summary
Frames Received/Transmitted Number of packets transmitted and received without Drops Received/Transmitted show t3 summary show t3 summary You can specify any of the following filters (flags) with this command: -slot <arg> -name <arg> <arg 1> The output includes the following information: T3 over Mct3 summary Name Slot/Conn...
Page 207: Show T3 Vc Qos Stats
QoS Package WAN Protocol show t3 vc qos stats show t3 vc qos stats packets and bytes transmitted and received over the frame relay DLCI VC (virtual circuit) for queues configured through a service package. You can specify any of the following filters (flags) with this command: -slot <arg>...
Page 208: Show T3 Vc Stats
T3 over Mcoc3 vc qos stats Interface/DLCI Cct/Queue RxBelowCIR Packets/Octets RxAboveCIR Packets/Octets RxAboveBR Packets/Octets Tx Packets/Octets Dropped Packets show t3 vc stats show t3 vc stats packets and bytes transmitted and received over the frame relay DLCI VC (virtual circuit). This command allows for the following options: -slot <arg>...
Page 209 RxAboveBR Packets/Octets Tx Packets/Octets Dropped Packets T3 over Mcoc3 vc stats Interface/DLCI Circuit RxBelowCIR Packets/Octets Number of packets/octets received that were below the RxAboveCIR Packets/Octets Number of packets/octets received that exceeded the RxAboveBR Packets/Octets Tx Packets/Octets Dropped Packets 308689-B Rev 00 Number of packets/octets received that exceeded the allocated BR.
Page 210: Tcp Show Commands
TCP Show Commands This section describes the TCP show commands and the command options you can enter. It also describes the information in the tables the router displays. show tcp connections show tcp connections Transmission Control Protocol (TCP) connection. The table includes the IP address, port numbers, and state associated with each connection.
Page 211 Maximum transmit and receive window size that TCP allows for each connection. Algorithm for determining when to retransmit unacknowledged packets. Currently, Nortel Networks implements the Van Jacobson algorithm only. Number of times TCP connections have made a direct transition to the syn-sent state from the closed state.
Page 212: Telnet Show Command
Telnet Show Command This section describes the Telnet show command and the information in the tables the router displays. show telnet show telnet includes the following information: Telnet Server Statistics State Prompt Lines/Screen Max. Login Retries Login Timeout (min.) Passwd. Timeout (min.) Command Timeout (min.) Telnet Client Statistics State...
Page 213: Tftp Show Command
TFTP Show Command This section describes the TFTP show command and information in the tables the router displays. show tftp show tftp Protocol (TFTP) status. The output includes the following information: TFTP Protocol Default Volume Retransmit Timeout Value (sec.) Maximum Number of Retransmits Number of Writes Received Number of Reads Received...
Page 214: Version Show Command
Version Show Command This section describes the version show command and information in the tables the router displays. show version show version software version, and sources of configuration files and boot images. The output displays the following information about the system: CNS Software, Version xxx/xxx/xx/x Compiled...

Nortel Versalar 15000 Reference Manual

Preface

The Show Commands

Quick Links

Related Manuals for Nortel Versalar 15000

Summary of Contents for Nortel Versalar 15000
