Table 2–9. Video Port Interrupt Status Register (VPIS) Field Descriptions (Continued)
Bit
field
symval
22
SFDB
NONE
CLEAR
21
VINTB2
NONE
CLEAR
20
VINTB1
NONE
CLEAR
19
SERRB
NONE
CLEAR
† For CSL implementation, use the notation VP_VPIS_field_symval
SPRU629
Value
Description
Short field detected on channel B interrupt detected bit.
BT.656 or Y/C capture mode – SFDB is set when short field
detection is enabled and VCOUNT is reset before
VCOUNT = YSTOP.
Raw data mode, or TSI capture mode or display mode – Not used.
0
No interrupt is detected.
1
Interrupt is detected. Bit is cleared.
Channel B field 2 vertical interrupt detected bit.
BT.656 or Y/C capture mode – VINTB2 is set when a vertical
interrupt occurred in field 2.
Raw data mode or TSI capture mode – Not used.
0
No interrupt is detected.
1
Interrupt is detected. Bit is cleared.
Channel B field 1 vertical interrupt detected bit.
BT.656 or Y/C capture mode – VINTB1 is set when a vertical
interrupt occurred in field 1.
Raw data mode or TSI capture mode – Not used.
0
No interrupt is detected.
1
Interrupt is detected. Bit is cleared.
Channel B synchronization error interrupt detected bit.
BT.656 or Y/C capture mode – Synchronization parity error on
channel B. An SERRB typically requires resetting the channel
(RSTCH) or the port (VPRST).
Raw data mode or TSI capture mode – Not used.
0
No interrupt is detected.
1
Interrupt is detected. Bit is cleared.
Video Port Control Registers
Video Port
2-25
