Table 5–4. Video Port Pin Function Register (PFUNC) Field Descriptions (Continued)
†
Bit
field
symval
20
PFUNC20
NORMAL
VCTL1
19–11
Reserved
–
10
PFUNC10
NORMAL
VDATA10TO19
9–1
Reserved
–
0
PFUNC0
NORMAL
VDATA0TO9
† For CSL implementation, use the notation VP_PFUNC_field_symval
SPRU629
†
Value
Description
PFUNC20 bit determines if VCTL1 pin functions as GPIO.
0
Pin functions normally.
1
Pin functions as GPIO pin.
0
Reserved. The reserved bit location is always read as 0. A
value written to this field has no effect.
PFUNC10 bit determines if VDATA[19–10] pins function as
GPIO.
0
Pins function normally.
1
Pins function as GPIO pin.
0
Reserved. The reserved bit location is always read as 0. A
value written to this field has no effect.
PFUNC0 bit determines if VDATA[9–0] pins function as
GPIO.
0
Pins function normally.
1
Pins function as GPIO pin.
GPIO Registers
General Purpose I/O Operation
5-7
